Schweitzer Engineering Laboratories SEL-421-4 - Figure 4.12 Bay Control Screen Selected for Rotating Display

4.16
SEL-421 Relay Instruction Manual Date Code 20171021
Front-Panel Operations
One-Line Diagrams
You can also configure an HMI pushbutton to give you direct access to the bay
control screen. Figure 4.13 shows an example of how to configure HMI Pushbut-
ton 1 by selecting the BC option from the drop-down menu.
Figure 4.12 Bay Control Screen Selected for Rotating Display
