Schweitzer Engineering Laboratories SEL-421-4 - Table 11.61 Relay Word Bits: Local Bit Supervision; Table 11.62 Relay Word Bits: Local Bit Status; Table 11.63 Relay Word Bits: RTC Remote Digital Status; Table 11.64 Relay Word Bits: Fast Operate Transmit Bits

11.67
Date Code 20171021 Instruction Manual SEL-421 Relay
Relay Word Bits
Row Lists
Table 11.61 Relay Word Bits: Local Bit Supervision
Row Name Description
304 LB_SP01–LB_SP08 Local Bit 01–08 supervision (SELOGIC Equation)
305 LB_SP09–LB_SP16 Local Bit 09–16 supervision (SEL
OGIC Equation)
306 LB_SP17–LB_SP24 Local Bit 17–24 supervision (SEL
OGIC Equation)
307 LB_SP25–LB_SP32 Local Bit 25–32 supervision (SEL
OGIC Equation)
Table 11.62 Relay Word Bits: Local Bit Status
Row Name Description
308 LB_DP01–LB_DP08 Local Bit 01–08 status display (SELOGIC Equation)
309 LB_DP09–LB_DP16 Local Bit 09–16 status display (SEL
OGIC Equation)
310 LB_DP17–LB_DP24 Local Bit 17–24 status display (SEL
OGIC Equation)
311 LB_DP25–LB_DP32 Local Bit 25–32 status display (SEL
OGIC Equation)
Table 11.63 Relay Word Bits: RTC Remote Digital Status
Row Name Description
312 RTCAD01–RTCAD08 RTC remote data bits, Channel A, Bit 1–8
313 RTCAD09–RTCAD16 RTC remote data bits, Channel A, Bit 9–16
314 RTCBD01–RTCBD08 RTC remote data bits, Channel B, Bit 1–8
315 RTCBD09–RTCBD16 RTC remote data bits, Channel B, Bit 9–16
Table 11.64 Relay Word Bits: Fast Operate Transmit Bits
Row Name Description
316 FOPF_01–FOPF_08 Fast-operate output control bits for Port F, Bit 1–8
317 FOPF_09–FOPF_16 Fast-operate output control bits for Port F, Bit 9–16
318 FOPF_17–FOPF_24 Fast-operate output control bits for Port F, Bit 17–24
319 FOPF_25–FOPF_32 Fast-operate output control bits for Port F, Bit 25–32
320 FOP1_01–FOP1_08 Fast-operate output control bits for Port 1, Bit 1–8
321 FOP1_09–FOP1_16 Fast-operate output control bits for Port 1, Bit 9–16
322 FOP1_17–FOP1_24 Fast-operate output control bits for Port 1, Bit 17–24
323 FOP1_25–FOP1_32 Fast-operate output control bits for Port 1, Bit 25–32
324 FOP2_01–FOP2_08 Fast-operate output control bits for Port 2, Bit 1–8
325 FOP2_09–FOP2_16 Fast-operate output control bits for Port 2, Bit 9–16
326 FOP2_17–FOP2_24 Fast-operate output control bits for Port 2, Bit 17–24
327 FOP2_25–FOP2_32 Fast-operate output control bits for Port 2, Bit 35–32
328 FOP3_01–FOP3_08 Fast-operate output control bits for Port 3, Bit 1–8
329 FOP3_09–FOP3_16 Fast-operate output control bits for Port 3, Bit 9–16
330 FOP3_17–FOP3_24 Fast-operate output control bits for Port 3, Bit 17–24
331 FOP3_25–FOP3_32 Fast-operate output control bits for Port 3, Bit 25–32
