SEL-421 Relay Instruction Manual Date Code 20171021
Settings
Global Settings
Make Table 8.20 settings when Global enable setting EDRSTC := Y.
PMLER Length of PMU Triggered Data (2–120 s) 30
PMPRE Length of PMU Pre-Triggered Data (1–20 s) 5
Table 8.18 Synchronized Phasor Real Time Control Settings
Setting Prompt Default
RTCRATE Remote Messages per Second
(1, 2, 5, 10, or 50 when NFREQ := 50)
(1, 2, 4, 5, 10, 12, 15, 20, 30, or 60 when NFREQ := 60)
2
MRTCDLY Maximum RTC Synchrophasor Packet Delay (20–1000 ms) 500
Table 8.19 Time and Date Management
Setting Prompt Default Value
DATE_F Date Format (MDY, YMD, DMY) MDY
IRIGC
a
a
When EPMU = Y and MFRMT = C37.118, IRIGC is forced to C37.118.
IRIG-B Control Bits Definition (None, C37.118) None
UTCOFF
b
b
All data, reports, and commands from the relay are stored and displayed in local time, referenced
to an internal UTC master clock. Use the UTCOFF setting to specify the time offset from UTC
time reference with respect to the relay location. (The only data still displayed in UTC time is
streaming synchrophasor and IEC 61850 data.)
Offset From UTC to Local Time (–15.5 to 15.5) –8
BEG_DST
c
c
The BEG_DST (and END_DST) daylight-saving time setting consists of four fields or OFF:
hh = local time hour (0–23); defines when daylight-saving time begins.
n = the week of the month when daylight-saving time begins (1–3, L); occurs in either the 1st, 2nd,
3rd, or last week of the month.
d = day of week (1–7); Sunday is the first day of the week.
mm = month (1–12).
OFF = hides the daylight-saving time settings.
Begin DST (hh, n, d, mm, or OFF) “2, 2, 1, 3”
END_DST End DST (hh, n, d, mm) “2, 1, 1, 11”
Ta b l e 8 .20 D a ta Re s et Co n t r o l (S h e et 1 of 2 )
Setting Prompt Default Value
RST_DEM Reset Demand Metering (SELOGIC Equation) NA
RST_PDM Reset Peak Demand Metering (SEL
OGIC Equation) NA
RST_ENE Reset Energy Metering (SEL
OGIC Equation) NA
RSTMML Reset Maximum/Minimum Line (SEL
OGIC Equation) NA
RSTMMB1 Reset Maximum/Minimum Breaker 1 (SEL
OGIC Equation) NA
RSTMMB2 Reset Maximum/Minimum Breaker 2 (SEL
OGIC Equation) NA
RST_BK1 Reset Monitoring Breaker 1 (SEL
OGIC Equation) NA
RST_BK2 Reset Monitoring Breaker 2 (SEL
OGIC Equation) NA
RST_BAT Reset Battery Monitoring (SEL
OGIC Equation) NA
RST_79C Reset Recloser Shot Count Accumulators (SEL
OGIC Equation) NA
RSTTRGT Target Reset (SEL
OGIC Equation) NA
RSTFLOC Reset Fault Locator (SEL
OGIC Equation) NA
Table 8.17 Synchronized Phasor Recorder Settings (Sheet 2 of 2)
Setting Prompt Default
