Firmware Upgrade Instructions
Time-Domain Link (TiDL) Firmware Upgrade
This only affects time stamps recorded and stored by the relay prior to the firm-
ware upgrade. All time stamps in Demand Metering and Breaker Monitoring fol-
lowing the firmware upgrade will be UTC time with the local time offset setting
(UTCOFF) and daylight-saving time applied.
No other reports (Event History, Event Summary, SER, etc.) are affected.
Time-Domain Link (TiDL) Firmware Upgrade
The relay firmware will be upgraded through the standard upgrade process shown
above. The TiDL interface board has its own firmware upgrade process, and the
firmware for the TiDL interface board is stored on an SD card. This procedure
will upgrade the TiDL interface board as well as the connected Axion modules.
The firmware for the TiDL interface board can be determined by issuing the
VERSION command in the relay (see Figure B.6).
To upgrade the firmware, perform the following steps.
Remove From Service
Step 1. Remove the unit from service.
Step 2. Turn the unit off.
Step 3. Remove the front panel.
Upgrade
Step 1. Copy the ECB and SEL-2245 firmware .zds files from the upgrade
CD to an SD card.
Step 2. Install the SD card in the SD card slot indicated in Figure B.7.
Step 3. Turn the unit on.
Step 4. Wait for the upgrade to complete. (See the accompanying note.)
=>>VER <ENTER>
FID=SEL-451-5-R317-V0-Z022012-D20160728
CID=FFE8
Part Number: 0451543RRC4X4H60X0XXX
Serial Number: 0000000000
SELboot:
BFID= SLBT-4XX-R209-V0-Z001002-D20150130
Checksum: 0000
ECB FID= R100
Mainboard:
Code FLASH Size: 12 MB
Data FLASH Size: 52 MB
RAM Size: 64 MB
EEPROM Size: 128 kB
Front Panel: not installed
Analog Inputs (provided by remote Axion Nodes):
W: Currents: 5 Amp
X: Currents: 5 Amp
Y: Voltage: 67 Volts
Z: Voltage: 67 Volts
Interface Boards:
Board 1: not installed
Remote I/O: 72 inputs 48 outputs
E4 Configuration: 4
Extended Relay Features:
IEC 61850
Figure B.6 EtherCAT Cal Board (ECB) FID
