Make Table 8.8 settings for Interface Board #1 when Global enable setting
EICIS := Y.
Make Table 8.9 settings for Interface Board #2 when Global enable setting
EICIS := Y.
Table 8.8 Interface Board #1 Control Inputs
Setting Prompt Default Value Increment
IN201P
a
a
Setting is not available for interface boards INT2, INT4, INT7, and INT8. Set to Global setting
GINP when EICIS := N.
Input IN201 Pickup Level (15–265 Vdc) 85
b
b
Factory set at 18 for 24–48 Vdc rated power supply, 36 for 48–125 Vdc rated power supply, and
85 for 125–240 Vdc rated power supply. See
Control Inputs on page 2.6 for setting guidelines.
1
•
•
•
•
•
•
•
•
•
•
•
•
IN2mmP
a
Input IN2mm Pickup Level (15–265 Vdc) 85
b
1
IN201PU Input IN201 Pickup Delay (0.0000–5 cyc
c
)
c
If the interface board has more than eight input contacts, the upper range is 1 cycle.
0.1250
d
d
Set to Global setting IN2XXD when EICIS :-= N
0.0001
IN201DO Input IN201 Dropout Delay (0.0000–5 cyc
c
) 0.1250
d
0.0001
•
•
•
•
•
•
•
•
•
•
•
•
IN2mmPU
e
e
mm is the number of available input contacts on the interface board.
Input IN2mm
e
Pickup Delay (0.0000–5 cyc
c
) 0.1250
d
0.0001
IN2mmDO
e
Input IN2mm
e
Dropout Delay (0.0000–5 cyc
c
) 0.1250
d
0.0001
Table 8.9 Interface Board #2 Control Inputs
Setting Prompt Default Value Increment
IN301P
a
a
Setting is not available for interface boards INT2, INT4, INT7, and INT8. Set to Global setting
GINP when EICIS := N.
Input IN301 Pickup Level (15–265 Vdc) 85
b
b
Factory set at 18 for 24–48 Vdc rated power supply, 36 for 48–125 Vdc rated power supply, and
85 for 125–240 Vdc rated power supply. See
Control Inputs on page 2.6 for setting guidelines.
1
•
•
•
•
•
•
•
•
•
IN3mmP
a
Input IN3mm Pickup Level (15–265 Vdc) 85
b
1
IN301PU Input IN301 Pickup Delay (0.0000–5 cyc
c
)
c
If the interface board has more than eight input contacts, the upper range is 1 cycle.
0.1250
d
d
Set to Global setting IN3XXD when EICIS := N.
0.0001
IN301DO Input IN301 Dropout Delay (0.0000–5 cyc
c
)0.1250
d
0.0001
•
•
•
•
•
•
•
•
•
IN3mmPU
e
e
mm is the number of available input contacts on the interface board.
Input IN3mm
e
Pickup Delay (0.0000–5 cyc
c
)0.1250
d
0.0001
IN3mmDO
e
Input IN3mm
e
Dropout Delay (0.0000–5 cyc
c
)0.1250
d
0.0001
