Table 11.65 Relay Word Bits: Bay Control Disconnect Status (Sheet 1 of 2)
Row Name Description
332 89AM01 Disconnect 1 N/O auxiliary contact
332 89BM01 Disconnect 1 N/C auxiliary contact
332 89CL01 Disconnect 1 closed
332 89OPN01 Disconnect 1 open
332 89OIP01 Disconnect 1 operation in-progress
332 89AL01 Disconnect 1 alarm
332 * Reserved
332 89AL Any disconnect alarm
333 89AM02 Disconnect 2 N/O auxiliary contact
333 89BM02 Disconnect 2 N/C auxiliary contact
333 89CL02 Disconnect 2 closed
333 89OPN02 Disconnect 2 open
333 89OIP02 Disconnect 2 operation in-progress
333 89AL02 Disconnect 2 alarm
333 * Reserved
333 89OIP Any Disconnect operation in-progress
334 89AM03 Disconnect 3 N/O auxiliary contact
334 89BM03 Disconnect 3 N/C auxiliary contact
334 89CL03 Disconnect 3 closed
334 89OPN03 Disconnect 3 open
334 89OIP03 Disconnect 3 operation in-progress
334 89AL03 Disconnect 3 alarm
334 * Reserved
334 LOCAL Local front-panel control
335 89AM04 Disconnect 4 N/O auxiliary contact
335 89BM04 Disconnect 4 N/C auxiliary contact
335 89CL04 Disconnect 4 closed
335 89OPN04 Disconnect 4 open
335 89OIP04 Disconnect 4 operation in-progress
335 89AL04 Disconnect 4 alarm
335 * Reserved
335 * Reserved
336 89AM05 Disconnect 5 N/O auxiliary contact
336 89BM05 Disconnect 5 N/C auxiliary contact
336 89CL05 Disconnect 5 closed
336 89OPN05 Disconnect 5 open
336 89OIP05 Disconnect 5 operation in-progress
336 89AL05 Disconnect 5 alarm
336 * Reserved
336 * Reserved
337 89AM06 Disconnect 6 N/O auxiliary contact
