Schweitzer Engineering Laboratories SEL-421-4 - Table 10.9 SEL-421 Database Structure-ANALOGS Region

10.7
Date Code 20171021 Instruction Manual SEL-421 Relay
Communications Interfaces
Communications Database
The ANALOGS region contains protection and automation variables. This region
is updated every 0.5 seconds. See Table 10.9 for the Map.
The database is virtual device 1 in the relay. You can display the contents of a
region using the MAP 1:region command (where region is one of the database
region names listed in Table 10.1). An example of the MAP command is shown
in Figure 10.1.
600D CH10(mV) int Channel 10 offset
600E CH11(mV) int Channel 11 offset
600F CH12(mV) int Channel 12 offset
6010 MOF(mV) int Master offset
6011 OFF_WARN char[8] Offset warning string
6019 OFF_FAIL char[8] Offset failure string
6021 PS3(V) float 3.3 Volt power supply voltage
6023 PS5(V) float 5 Volt power supply voltage
6025 PS_N5(V) float –5 Volt regulated voltage
6027 PS15(V) float 15 Volt power supply voltage
6029 PS_N15(V) float –15 Volt power supply voltage
602B PS_WARN char[8] Power supply warning string
6033 PS_FAIL char[8] Power supply failure string
603B HW_FAIL char[40] Hardware failure strings
6063 CC_STA char[40] Comm. card status strings
608B PORT_STA char[160] Serial port status strings
612B TIME_SRC char[10] Time source
6135 LOG_ERR char[40] SEL
OGIC error strings
615D TEST_MD char[160] Test mode string
Table 10.9 SEL-421 Database Structure—ANALOGS Region
Address
(Hex)
Name Type Description
7000 _YEAR int Four-digit year when data were sampled
7001 DAY_OF_YEAR int 1–366 day when data were sampled
7002 TIME(ms) long int Time of day in ms when data were sampled
(0–86400000)
7004 PMV01_64 float[64] PMV01–PMV64
7084 AMV001_256 float[256] AMV001–AMV256
Table 10.8 SEL-421 Database Structure—STATUS Region (Sheet 2 of 2)
Address
(Hex)
Name Type Description
