SEL-400 Series Relays Instruction Manual Date Code 20171006
IEC 61850 Communication
ACSI Conformance Statements
ACSI Conformance Statements
Table 17.27 Basic Conformance Statement
Services
Client/
Subscriber
a
a
Y = supported
N or blank = not supported
Server/
Publisher
a
Value/
Comments
a
Client-Server Roles
B11 Server side (of TWO-PARTY-APPLICATION-ASSOCIATION) Y
B12 Client side (of TWO-PARTY-APPLICATION-ASSOCIATION)
SCSMs Supported
B21 SCSM: IEC 6185-8-1 used Y
B22 SCSM: IEC 6185-9-1 used Deprecated in
Edition 2
B23 SCSM: IEC 6185-9-2 used
B24 SCSM: other
Generic Substation Event (GSE) Model
B31 Publisher side Y
B32 Subscriber side Y
Transmission of Sampled Value Model (SVC)
B41 Publisher side
B42 Subscriber side Y
Table 17.28 ACSI Models Conformance Statement (Sheet 1 of 2)
Client/Subscriber
a
Server/Publisher
a
Value/Comments
If Server Side (B11) and/or Client Side (B12) Supported
M1 Logical device Y
M2 Logical node Y
M3 Data Y
M4 Data set Y
M5 Substitution
M6 Setting group control Y
Reporting
M7 Buffered report control Y
M7–1 sequence-number Y
M7–2 report-time-stamp Y
M7–3 reason-for-inclusion Y
M7–4 data-set-name Y
M7–5 data-reference Y
M7–6 buffer-overflow Y
M7–7 entryID Y
M7–8 BufTim Y
M7–9 IntgPd Y
M7–10 GI Y
