SECTION 12
Analog Quantities
This section contains tables of the analog quantities available within the SEL-421
Relay.
Use Table 12.1 and Table 12.2 as a reference for labels in this manual and as a
resource for quantities you use in SEL
OGIC control equation relay settings.
Table 12.1 lists the analog quantities alphabetically, and Tab le 12.2 groups the
analog quantities by function.
Table 12.1 Analog Quantities Sorted Alphabetically (Sheet 1 of 12)
Label Description Unit
3DPF Three-phase displacement power factor NA
3I0WFA Terminal W, zero-sequence filtered current, angle Degrees [°] (±180°)
3I0WFI Terminal W, zero-sequence filtered current, imaginary component Amperes [A] (secondary)
3I0WFM Terminal W, zero-sequence filtered current, magnitude Amperes [A] (secondary)
3I0WFR Terminal W, zero-sequence filtered current, real component Amperes [A] (secondary)
3I0XFA Terminal X, zero-sequence filtered current, angle Degrees [°] (±180°)
3I0XFI Terminal X, zero-sequence filtered current, imaginary component Amperes [A] (secondary)
3I0XFM Terminal X, zero-sequence filtered current, magnitude Amperes [A] (secondary)
3I0XFR Terminal X, zero-sequence filtered current, real component Amperes [A] (secondary)
3I2D Demand negative-sequence current Amperes [A] (secondary)
3I2PKD Peak demand negative-sequence current Amperes [A] (primary)
3IA2WFA Terminal W, negative-sequence filtered current, angle Degrees [°] (±180°)
3IA2WFI Terminal W, negative-sequence filtered current, imaginary component Amperes [A] (secondary)
3IA2WFM Terminal W, negative-sequence filtered current, magnitude Amperes [A] (secondary)
3IA2WFR Terminal W, negative-sequence filtered current, real component Amperes [A] (secondary)
3IA2XFA Terminal X, negative-sequence filtered current, angle Degrees [°] (±180°)
3IA2XFI Terminal X, negative-sequence filtered current, imaginary component Amperes [A] (secondary)
3IA2XFM Terminal X, negative-sequence filtered current, magnitude Amperes [A] (secondary)
3IA2XFR Terminal X, negative-sequence filtered current, real component Amperes [A] (secondary)
3MWH3T Total three-phase energy; Megawatt-hours Megawatt-hour [MWh] (primary)
3MWHIN Negative (import) three-phase energy, Megawatt-hours Megawatt-hour [MWh] (primary)
3MWHOUT Positive (export) three-phase energy, Megawatt-hours Megawatt-hour [MWh] (primary)
3P Three-phase real power Megawatts [MW] (primary)
3P_F Fundamental real power (three-phase) Megawatts [MW] (primary)
3PD Demand three-phase real power Megawatts [MW] (primary)
3PF Three-phase power factor N/A
3PPKD Peak demand three-phase real power Megawatts [MW] (primary)
3PSHOT Present value of three-pole shot counter N/A
