9.7
Date Code 20171021 Instruction Manual SEL-421 Relay
ASCII Command Reference
Description of Commands
SHOW
See SHOW on page 14.50 in the SEL-400 Series Relays Instruction Manual. The
following table lists the class and instance options available in the SEL-421.
Table 9.7 SHO Command Overview
Command Description Access Level
SHO
a
a
Parameter
n
= 1–6, representing Group 1 through Group 6.
Show the Group relay settings, beginning at the first
setting in the active group.
1, B, P, A, O, 2
SHO n
a
Show the Group n relay settings, beginning at the first
setting in each instance.
1, B, P, A, O, 2
SHO A
b
b
Parameter
m
= 1–10 for Block 1 through Block 10.
Show the Automation SELOGIC control equation relay
settings in Block 1.
1, B, P, A, O, 2
SHO A m
b
Show the Automation SELOGIC control equation relay
settings in Block m.
1, B, P, A, O, 2
SHO B Show the Bay Control relay settings, beginning at the
first setting in this class.
1, B, P, A, O, 2
SHO D Show the DNP3 remapping settings for instance 1. P, A, O, 2
SHO D instance Show the DNP3 remapping settings for instance. P, A, O, 2
SHO F Show the front-panel relay settings, beginning at the
first setting in this class.
1, B, P, A, O, 2
SHO G Show the Global relay settings, beginning at the first
setting in this class.
1, B, P, A, O, 2
SHO L
a
Show the Protection SELOGIC control equation relay
settings for the active group.
1, B, P, A, O, 2
SHO L n
a
Show the Protection SELOGIC control equation relay
settings for Instance n, which is Group n.
1, B, P, A, O, 2
SHO M Show the Breaker Monitor relay settings, beginning at
the first setting in this class.
1, B, P, A, O, 2
SHO N Show notes in the relay. 1, B, P, A, O, 2
SHO O Show the Output SEL
OGIC control equation relay set-
tings, beginning at OUT101.
1, B, P, A, O, 2
SHO P
c
c
Parameter
p
= 1–3, F, and 5, which corresponds to PORT 1–PORT 3, PORT F, and PORT 5.
Show the relay settings for the port presently in use,
beginning at the first setting.
1, B, P, A, O,
SHO P p
c
Show the communications Port relay settings for
Port p, beginning at the first setting for this port.
1, B, P, A, O, 2
SHO R Show the Report relay settings, beginning at the first
setting for this class.
1, B, P, A, O, 2
SHO T Show the alias settings. 1, B, P, A, O, 2
