17.44
SEL-400 Series Relays Instruction Manual Date Code 20171006
IEC 61850 Communication
Protocol Implementation Conformance Statement
Protocol Implementation Conformance Statement
Table 17.14 and Table 17.15 are as shown in the IEC 61850 standard, Part 8-1,
Section 24. Note that because the standard explicitly dictates which services and
functions must be implemented to achieve conformance, only the optional ser-
vices and functions are listed.
Refer to the ACSI Conformance Statements on page 17.50 for information on the
supported services.
MMS Conformance
The manufacturing message specification (MMS) stack provides the basis for
many IEC 61850 protocol services. Table 17.16 defines the service support
requirement and restrictions of the MMS services in the SEL-400 series devices.
Generally, only those services whose implementation is not mandatory are
shown. Refer to the IEC 61850 standard Part 8-1 for more information.
configRev Always 0
1dNs IEC 61850-7-4:2007A
Table 17.13 SEL Nameplate Data (Sheet 2 of 2)
Data Attribute Value
Table 17.14 PICS for A-Profile Support
Profile Client Server Value/Comment
A1 Client/Server N Y
A2 GOOSE/GSE management Y Y Only GOOSE, not GSSE
management
A3 GSSE N N
A4 Time Sync N N
Table 17.15 PICS for T-Profile Support
Profile Client Server Value/Comment
T1 TCP/IP N Y
T2 OSI N N
T3 GOOSE/GSE Y Y Only GOOSE, not GSSE
T4 GSSE N N
T5 Time Sync N N
Table 17.16 MMS Service Supported Conformance (Sheet 1 of 4)
MMS Service Supported CBB
Client-CR Server-CR
Supported Supported
status Y
getNameList Y
identify Y
rename
