Date Code 20171006 Instruction Manual SEL-400 Series Relays
IEC 61850 Communication
Logical Nodes
SEL Nameplate Data
The CID file contains information that describes the physical device attributes
according to IEC 61850 standards. The LN0 logical node of each logical device
contains the Nameplate DOI (instantiated data object) with the following data.
TMBBGGIO12 Ind01.stVal TMB1B Channel B Transmit Mirrored Bit 1
TMBBGGIO12 Ind02.stVal TMB2B Channel B Transmit Mirrored Bit 2
TMBBGGIO12 Ind03.stVal TMB3B Channel B Transmit Mirrored Bit 3
TMBBGGIO12 Ind04.stVal TMB4B Channel B Transmit Mirrored Bit 4
TMBBGGIO12 Ind05.stVal TMB5B Channel B Transmit Mirrored Bit 5
TMBBGGIO12 Ind06.stVal TMB6B Channel B Transmit Mirrored Bit 6
TMBBGGIO12 Ind07.stVal TMB7B Channel B Transmit Mirrored Bit 7
TMBBGGIO12 Ind08.stVal TMB8B Channel B Transmit Mirrored Bit 8
VBGGIO1 Ind001.stVal VB001 Virtual Bit 001
VBGGIO1 Ind002.stVal VB002 Virtual Bit 002
VBGGIO1 Ind003.stVal VB003 Virtual Bit 003
•
•
•
VBGGIO1 Ind126.stVal VB126 Virtual Bit 126
VBGGIO1 Ind127.stVal VB127 Virtual Bit 127
VBGGIO1 Ind128.stVal VB128 Virtual Bit 128
VBGGIO2 Ind129.stVal VB129 Virtual Bit 129
VBGGIO2 Ind130.stVal VB130 Virtual Bit 130
VBGGIO2 Ind131.stVal VB131 Virtual Bit 131
•
•
•
VBGGIO2 Ind254.stVal VB254 Virtual Bit 254
VBGGIO2 Ind255.stVal VB255 Virtual Bit 255
VBGGIO2 Ind256.stVal VB256 Virtual Bit 256
a
Data attributes in the ST FC will provide high-speed GOOSE data if included in an outgoing
GOOSE dataset.
b
Not all SEL-400 series relays support main board inputs.
c
Not all SEL-400 series relays support a third interface board.
d
Not all SEL-400 series relays support four interface boards.
e
Not all SEL-400 series relays support main board outputs.
Table 17.12 Logical Device: ANN (Annunciation) (Sheet 11 of 11)
Logical Node Attribute
Data
Source
Comment
Table 17.13 SEL Nameplate Data (Sheet 1 of 2)
Data Attribute Value
vendor “SEL”
swRev Contents of FID string from ID command
d Description of LD
To Next Page
