17.42
SEL-400 Series Relays Instruction Manual Date Code 20171006
IEC 61850 Communication
Logical Nodes
SGGGIO1 Ind01.stVal SG1 Settings Group 1 active
SGGGIO1 Ind02.stVal SG2 Settings Group 2 active
SGGGIO1 Ind03.stVal SG3 Settings Group 3 active
SGGGIO1 Ind04.stVal SG4 Settings Group 4 active
SGGGIO1 Ind05.stVal SG5 Settings Group 5 active
SGGGIO1 Ind06.stVal SG6 Settings Group 6 active
TLEDGGIO7 Ind01.stVal EN Relay Enabled
TLEDGGIO7 Ind02.stVal TRIPLED Trip LED
TLEDGGIO7 Ind03.stVal TLED_1 Target LED 1
TLEDGGIO7 Ind04.stVal TLED_2 Target LED 2
TLEDGGIO7 Ind05.stVal TLED_3 Target LED 3
TLEDGGIO7 Ind06.stVal TLED_4 Target LED 4
TLEDGGIO7 Ind07.stVal TLED_5 Target LED 5
TLEDGGIO7 Ind08.stVal TLED_6 Target LED 6
TLEDGGIO7 Ind09.stVal TLED_7 Target LED 7
TLEDGGIO7 Ind10.stVal TLED_8 Target LED 8
TLEDGGIO7 Ind11.stVal TLED_9 Target LED 9
TLEDGGIO7 Ind12.stVal TLED_10 Target LED 10
TLEDGGIO7 Ind13.stVal TLED_11 Target LED 11
TLEDGGIO7 Ind14.stVal TLED_12 Target LED 12
TLEDGGIO7 Ind15.stVal TLED_13 Target LED 13
TLEDGGIO7 Ind16.stVal TLED_14 Target LED 14
TLEDGGIO7 Ind17.stVal TLED_15 Target LED 15
TLEDGGIO7 Ind18.stVal TLED_16 Target LED 16
TLEDGGIO7 Ind19.stVal TLED_17 Target LED 17
TLEDGGIO7 Ind20.stVal TLED_18 Target LED 18
TLEDGGIO7 Ind21.stVal TLED_19 Target LED 19
TLEDGGIO7 Ind22.stVal TLED_20 Target LED 20
TLEDGGIO7 Ind23.stVal TLED_21 Target LED 21
TLEDGGIO7 Ind24.stVal TLED_22 Target LED 22
TLEDGGIO7 Ind25.stVal TLED_23 Target LED 23
TLEDGGIO7 Ind26.stVal TLED_24 Target LED 24
TMBAGGIO10 Ind01.stVal TMB1A Channel A Transmit Mirrored Bit 1
TMBAGGIO10 Ind02.stVal TMB2A Channel A Transmit Mirrored Bit 2
TMBAGGIO10 Ind03.stVal TMB3A Channel A Transmit Mirrored Bit 3
TMBAGGIO10 Ind04.stVal TMB4A Channel A Transmit Mirrored Bit 4
TMBAGGIO10 Ind05.stVal TMB5A Channel A Transmit Mirrored Bit 5
TMBAGGIO10 Ind06.stVal TMB6A Channel A Transmit Mirrored Bit 6
TMBAGGIO10 Ind07.stVal TMB7A Channel A Transmit Mirrored Bit 7
TMBAGGIO10 Ind08.stVal TMB8A Channel A Transmit Mirrored Bit 8
Table 17.12 Logical Device: ANN (Annunciation) (Sheet 10 of 11)
Logical Node Attribute
Data
Source
Comment
