17.41
Date Code 20171006 Instruction Manual SEL-400 Series Relays
IEC 61850 Communication
Logical Nodes
RMBAGGIO9 Ind05.stVal RMB5A Channel A Receive Mirrored Bit 5
RMBAGGIO9 Ind06.stVal RMB6A Channel A Receive Mirrored Bit 6
RMBAGGIO9 Ind07.stVal RMB7A Channel A Receive Mirrored Bit 7
RMBAGGIO9 Ind08.stVal RMB8A Channel A Receive Mirrored Bit 8
RMBBGGIO11 Ind01.stVal RMB1B Channel B Receive Mirrored Bit 1
RMBBGGIO11 Ind02.stVal RMB2B Channel B Receive Mirrored Bit 2
RMBBGGIO11 Ind03.stVal RMB3B Channel B Receive Mirrored Bit 3
RMBBGGIO11 Ind04.stVal RMB4B Channel B Receive Mirrored Bit 4
RMBBGGIO11 Ind05.stVal RMB5B Channel B Receive Mirrored Bit 5
RMBBGGIO11 Ind06.stVal RMB6B Channel B Receive Mirrored Bit 6
RMBBGGIO11 Ind07.stVal RMB7B Channel B Receive Mirrored Bit 7
RMBBGGIO11 Ind08.stVal RMB8B Channel B Receive Mirrored Bit 8
RTCAGGIO1 Ind01.stVal RTCAD01 RTC Remote Data Bits, Channel A, bit 1
RTCAGGIO1 Ind02.stVal RTCAD02 RTC Remote Data Bits, Channel A, bit 2
RTCAGGIO1 Ind03.stVal RTCAD03 RTC Remote Data Bits, Channel A, bit 3
•
•
•
RTCAGGIO1 Ind14.stVal RTCAD14 RTC Remote Data Bits, Channel A, bit 14
RTCAGGIO1 Ind15.stVal RTCAD15 RTC Remote Data Bits, Channel A, bit 15
RTCAGGIO1 Ind16.stVal RTCAD16 RTC Remote Data Bits, Channel A, bit 16
RTCBGGIO2 Ind01.stVal RTCBD01 RTC Remote Data Bits, Channel B, bit 1
RTCBGGIO2 Ind02.stVal RTCBD02 RTC Remote Data Bits, Channel B, bit 2
RTCBGGIO2 Ind03.stVal RTCBD03 RTC Remote Data Bits, Channel B, bit 3
•
•
•
RTCBGGIO2 Ind14.stVal RTCBD14 RTC Remote Data Bits, Channel B, bit 14
RTCBGGIO2 Ind15.stVal RTCBD15 RTC Remote Data Bits, Channel B, bit 15
RTCBGGIO2 Ind16.stVal RTCBD16 RTC Remote Data Bits, Channel B, bit 16
RTDHGGIO1 Ind01.stVal RTD01ST RTD Status for Channel 1
RTDHGGIO1 Ind02.stVal RTD02ST RTD Status for Channel 2
RTDHGGIO1 Ind03.stVal RTD03ST RTD Status for Channel 3
RTDHGGIO1 Ind04.stVal RTD04ST RTD Status for Channel 4
RTDHGGIO1 Ind05.stVal RTD05ST RTD Status for Channel 5
RTDHGGIO1 Ind06.stVal RTD06ST RTD Status for Channel 6
RTDHGGIO1 Ind07.stVal RTD07ST RTD Status for Channel 7
RTDHGGIO1 Ind08.stVal RTD08ST RTD Status for Channel 8
RTDHGGIO1 Ind09.stVal RTD09ST RTD Status for Channel 9
RTDHGGIO1 Ind10.stVal RTD10ST RTD Status for Channel 10
RTDHGGIO1 Ind11.stVal RTD11ST RTD Status for Channel 11
RTDHGGIO1 Ind12.stVal RTD12ST RTD Status for Channel 12
Table 17.12 Logical Device: ANN (Annunciation) (Sheet 9 of 11)
Logical Node Attribute
Data
Source
Comment
NOTE: Not all relays support the
RMBAGGIO9 and RMBBGGIO11 logical
nodes.
NOTE: Not all relays support
synchrophasor real time control (RTC)
logical nodes.
NOTE: Not all relays support logical node
RTDHGGIO1 for RTD inputs.
To Next Page
