IEC 61850 Communication
Logical Nodes
OUT5GGIO18
d
Ind02.stVal OUT502 Fourth Optional I/O Board Output 2
OUT5GGIO18
d
Ind03.stVal OUT503 Fourth Optional I/O Board Output 3
•
•
•
OUT5GGIO18
d
Ind14.stVal OUT514 Fourth Optional I/O Board Output 14
OUT5GGIO18
d
Ind15.stVal OUT515 Fourth Optional I/O Board Output 15
OUT5GGIO18
d
Ind16.stVal OUT516 Fourth Optional I/O Board Output 16
PBLEDGGIO8 Ind01.stVal PB1_LED Pushbutton 1 LED
PBLEDGGIO8 Ind02.stVal PB2_LED Pushbutton 2 LED
PBLEDGGIO8 Ind03.stVal PB3_LED Pushbutton 3 LED
PBLEDGGIO8 Ind04.stVal PB4_LED Pushbutton 4 LED
PBLEDGGIO8 Ind05.stVal PB5_LED Pushbutton 5 LED
PBLEDGGIO8 Ind06.stVal PB6_LED Pushbutton 6 LED
PBLEDGGIO8 Ind07.stVal PB7_LED Pushbutton 7 LED
PBLEDGGIO8 Ind08.stVal PB8_LED Pushbutton 8 LED
PBLEDGGIO8 Ind09.stVal PB9_LED Pushbutton 9 LED
PBLEDGGIO8 Ind10.stVal PB10LED Pushbutton 10 LED
PBLEDGGIO8 Ind11.stVal PB11LED Pushbutton 11 LED
PBLEDGGIO8 Ind12.stVal PB12LED Pushbutton 12 LED
PLTGGIO2 Ind01.stVal PLT01 Protection Latch 1
PLTGGIO2 Ind02.stVal PLT02 Protection Latch 2
PLTGGIO2 Ind03.stVal PLT03 Protection Latch 3
•
•
•
PLTGGIO2 Ind30.stVal PLT30 Protection Latch 30
PLTGGIO2 Ind31.stVal PLT31 Protection Latch 31
PLTGGIO2 Ind32.stVal PLT32 Protection Latch 32
PSVGGIO1 Ind01.stVal PSV01 Protection SEL
OGIC Var iab l e 1
PSVGGIO1 Ind02.stVal PSV02 Protection SEL
OGIC Var iab l e 2
PSVGGIO1 Ind03.stVal PSV03 Protection SEL
OGIC Var iab l e 3
•
•
•
PSVGGIO1 Ind62.stVal PSV62 Protection SEL
OGIC Var iab l e 62
PSVGGIO1 Ind63.stVal PSV63 Protection SEL
OGIC Var iab l e 63
PSVGGIO1 Ind64.stVal PSV64 Protection SEL
OGIC Var iab l e 64
RMBAGGIO9 Ind01.stVal RMB1A Channel A Receive Mirrored Bit 1
RMBAGGIO9 Ind02.stVal RMB2A Channel A Receive Mirrored Bit 2
RMBAGGIO9 Ind03.stVal RMB3A Channel A Receive Mirrored Bit 3
RMBAGGIO9 Ind04.stVal RMB4A Channel A Receive Mirrored Bit 4
Table 17.12 Logical Device: ANN (Annunciation) (Sheet 8 of 11)
Logical Node Attribute
Data
Source
Comment
