Troubleshooting
Troubleshooting
Resolving Model Mismatch
When uploading a new firmware file to the relay, SELBOOT checks the relay
model number (for example, 451, 421, 487) to ensure that the firmware being
loaded into the relay is correct for the relay model. If the relay responds with
Transfer failed — Model mismatch when a firmware download is attempted, it
is because the relay model number does not match. This may be because the
firmware file is not correct, or the relay model number stored in the relay mem-
ory was corrupted by an interruption of the file download.
To remedy this problem, first ensure you are sending the correct file to the relay.
Table B.1 shows the file names used for the firmware files. Verify that the model
number in the firmware file matches the model of the relay being upgraded. After
confirming that the file is correct, restart the relay into SEL
BOOT. Do this by turn-
ing the relay off and back on while holding down the front-panel left and right
arrow navigation keys. The LCD will display
SELBOOT Ryyy once the power cycle
is complete. The data rate will reset to 9600 during this process. To increase the
data rate to the highest speed possible on the port, type BAU 115200 <Enter> at
the SEL
BOOT !> prompt (see Figure B.5). Switch the port communications
parameters data rate to 115200 and verify the SEL
BOOT prompt in the terminal
screen. At the SEL
BOOT prompt, issue a REC OVERRIDE command to the
relay. This tells the relay to bypass the model number check at the start of the
firmware upload process. Once the REC OVERRIDE command is issued, the
firmware upload process can be continued following the procedures in F Upload
New Relay Firmware on page B.11, starting with Step 2 on page B.11.
Resolving Status Failure Message Response to STA Command
If a status failure message is returned in response to the STA command, perform
the following steps.
Step 1. Use the ACC and 2AC commands with the associated passwords to
enter Access Level 2.
Step 2. Type STA C <Enter>. Answer Y <Enter> to the
Reboot the relay
and clear status
prompt. The relay will respond with Rebooting
the relay
. Wait for about 30 seconds, then press <Enter> until you
see the Access Level 0 = prompt.
Step 3. Use the ACC command with the associated password to enter Access
Level 1.
Step 4. Type STA <Enter>.
If there are no fail messages and you are using Method One, click
Next in Step 3 of 4 of the Firmware Loader and go to I Verify Relay
Settings on page B.13.
If there are no fail messages and you are using Method Two, go to
I Verify Relay Settings on page B.13.
If there are fail messages, continue with Step 5.
NOTE: Step 6 will cause the loss of
settings and other important data. Be
sure to retain relay settings and other
data downloaded from the relay at the
start of the firmware upgrade process.
Relay calibration level settings will not
be lost.
Step 5. Use the 2AC command with the associated password to enter Access
Level 2.
Step 6. Type R_S <Enter> to restore factory default settings in the relay.
The relay asks whether to restore default settings. If the relay does
not accept the R_S command, contact SEL for assistance.
