11.69
Date Code 20171021 Instruction Manual SEL-421 Relay
Relay Word Bits
Row Lists
337 89BM06 Disconnect 6 N/C auxiliary contact
337 89CL06 Disconnect 6 closed
337 89OPN06 Disconnect 6 open
337 89OIP06 Disconnect 6 operation in-progress
337 89AL06 Disconnect 6 alarm
337 * Reserved
337 * Reserved
338 89AM07 Disconnect 7 N/O auxiliary contact
338 89BM07 Disconnect 7 N/C auxiliary contact
338 89CL07 Disconnect 7 closed
338 89OPN07 Disconnect 7 open
338 89OIP07 Disconnect 7 operation in-progress
338 89AL07 Disconnect 7 alarm
338 * Reserved
338 * Reserved
339 89AM08 Disconnect 8 N/O auxiliary contact
339 89BM08 Disconnect 8 N/C auxiliary contact
339 89CL08 Disconnect 8 closed
339 89OPN08 Disconnect 8 open
339 89OIP08 Disconnect 8 operation in-progress
339 89AL08 Disconnect 8 alarm
339 * Reserved
339 * Reserved
340 89AM09 Disconnect 9 N/O auxiliary contact
340 89BM09 Disconnect 9 N/C auxiliary contact
340 89CL09 Disconnect 9 closed
340 89OPN09 Disconnect 9 open
340 89OIP09 Disconnect 9 operation in-progress
340 89AL09 Disconnect 9 alarm
340 * Reserved
340 * Reserved
341 89AM10 Disconnect 10 N/O auxiliary contact
341 89BM10 Disconnect 10 N/C auxiliary contact
341 89CL10 Disconnect 10 closed
341 89OPN10 Disconnect 10 open
341 89OIP10 Disconnect 10 operation in-progress
341 89AL10 Disconnect 10 alarm
341 * Reserved
341 * Reserved
Table 11.65 Relay Word Bits: Bay Control Disconnect Status (Sheet 2 of 2)
Row Name Description
