B.15
Date Code 20171021 Instruction Manual SEL-421 Relay
Converting Settings From SEL-421-0, -1, -2, -3 to SEL-421-4, -5
DNP3 Mapping Changes
Counters
In the SEL-421-0, -1, -2, -3 counters were referenced as points in the database.
None of these can be directly assigned to the counter values that are now avail-
able.
Analog Inputs
In the SEL-421-0, -1, -2, -3 analog inputs were referenced as points in the data-
base with optional type qualifiers. It is impractical to define a mapping from
these points to the data that is now available.
Analog Outputs
In the SEL-421-0, -1, -2, -3 analog outputs were referenced by index: 0–255.
These mapped to remote analogs: RA001–RA256. In the SEL-421-4, -5 these
same remote analogs are available. So, if previously, Index 0 was referenced, the
new reference is RA001. Similarly, Index 1 goes to RA002, etc.
163 RB07:RB08
164 RB09:RB10
165 RB11:RB12
166 RB13:RB14
167 RB15:RB16
168 RB17:RB18
169 RB19:RB20
170 RB21:RB22
171 RB23:RB24
172 RB25:RB26
173 RB27:RB28
174 RB29:RB30
175 RB31:RB32
176 OC1:CC1
177 OC2:CC2
178 89OC01:89CC01
179 89OC02:89CC02
180 89OC03:89CC03
181 89OC04:89CC04
182 89OC05:89CC05
183 89OC06:89CC06
184 89OC07:89CC07
185 89OC08:89CC08
186 89OC09:89CC09
187 89OC10:89CC10
Table B.13 Binary Outputs Mapping for DNP3 LAN/WAN (Sheet 2 of 2)
Numeric Reference Label Reference Notes
