11.71
Date Code 20171021 Instruction Manual SEL-421 Relay
Relay Word Bits
Row Lists
350 89CCM04 Mimic Disconnect 4 close control
350 89OPE04 Disconnect Open 4 output
350 89CLS04 Disconnect Close 4 output
350 89OCN04 Open Disconnect 4
350 89CCN04 Close Disconnect 4
351 * Reserved
352 89OC05 ASCII Open Disconnect 5 command
352 89CC05 ASCII Close Disconnect 5 command
352 89OCM05 Mimic Disconnect 5 open control
352 89CCM05 Mimic Disconnect 5 close control
352 89OPE05 Disconnect Open 5 output
352 89CLS05 Disconnect Close 5 output
352 89OCN05 Open Disconnect 5
352 89CCN05 Close Disconnect 5
353 * Reserved
354 89OC06 ASCII Open Disconnect 6 command
354 89CC06 ASCII Close Disconnect 6 command
354 89OCM06 Mimic Disconnect 6 open control
354 89CCM06 Mimic Disconnect 6 close control
354 89OPE06 Disconnect Open 6 output
354 89CLS06 Disconnect Close 6 output
354 89OCN06 Open Disconnect 6
354 89CCN06 Close Disconnect 6
355 * Reserved
356 89OC07 ASCII Open Disconnect 7 command
356 89CC07 ASCII Close Disconnect 7 command
356 89OCM07 Mimic Disconnect 7 open control
356 89CCM07 Mimic Disconnect 7 close control
356 89OPE07 Disconnect Open 7 output
356 89CLS07 Disconnect Close 7 output
356 89OCN07 Open Disconnect 7
356 89CCN07 Close Disconnect 7
357 * Reserved
358 89OC08 ASCII Open Disconnect 8 command
358 89CC08 ASCII Close Disconnect 8 command
358 89OCM08 Mimic Disconnect 8 open control
358 89CCM08 Mimic Disconnect 8 close control
358 89OPE08 Disconnect Open 8 output
358 89CLS08 Disconnect Close 8 output
358 89OCN08 Open Disconnect 8
358 89CCN08 Close Disconnect 8
Table 11.67 Relay Word Bits: Bay Control Disconnect Control (Sheet 2 of 3)
Row Name Description
