Settings Structure
Note that some settings classes have only one instance and you do not specify the
instance designator when accessing these classes. An example is the Global set-
tings class. You can view or modify Global settings with a communications ter-
minal by entering SET G as shown in the ASCII Command column of
Table 12.1. The relay presents the Global settings categories at the SET G com-
mand; no instance numbers follow SET G. Conversely, the Port settings com-
mand has five instances (PORT F, PORT 1, PORT 2, PORT 3, and PORT 5). To
access the PORT 1 settings, type SET P 1 <Enter>. If you do not specify which
port to set, the relay defaults to the active port (the port you are presently using).
The Group settings can have the optional one-letter acronym S attached to the
command; you can enter SET 1 or SET S 1 for Group 1 settings, SET 2 or
SET S 2 for Group 2 settings, etc. If you do not specify which group to set, the
Port Communications port settings PORT F
PORT 1
•
•
•
PORT 3
PORT 5
Front-panel port
PORT 1 settings
•
•
•
PORT 3 settings
Ethernet card settings
SET P F
SET P 1
•
•
•
SET P 3
SET P 5
P, A, O, 2
Report Event report and SER settings Report SET R P, A, O, 2
Front Panel Front-panel HMI settings Front Panel SET F P, A, O, 2
Protection
SEL
OGIC control
equations
Protection-related SEL
OGIC con-
trol equations
Group 1
•
•
•
Group 6
Group 1 protection
SEL
OGIC control equations
•
•
•
Group 6 protection
SEL
OGIC control equations
SET L 1
•
•
•
SET L 6
P, 2
Automation
SEL
OGIC control
equations
Automation-related SEL
OGIC
control equations
Block 1
•
•
•
Block 10
Block 1 automation
SEL
OGIC control equations
•
•
•
Block 10 automation
SEL
OGIC control equations
SET A 1
•
•
•
SET A 10
A, 2
DNP3 Distributed Network Protocol
data remapping
Map1
•
•
•
Map 5
SET D 1
•
•
•
SET D 5
P, A, O, 2
Output SEL
OGIC
control equations
Relay control output settings and
M
IRRORED BITS communications
transmit equations
Output SET O O, 2
Alias Set aliases Analog or
digital quanti-
ties
SET T P, A, O, 2
Notes Freeform programming to leave
notes in the relay
Notes 100 lines SET N P, A, O, 2
Table 12.1 Typical Settings Classes and Instances (Sheet 2 of 2)
Class Description Instance Description ASCII Command
Access
Level
