13.39
Date Code 20171006 Instruction Manual SEL-400 Series Relays
SELOGIC Control Equation Programming
SEL-311 and SEL-351 Series Users
In an SEL-400 series relay, use the format shown below.
Protection freeform style settings:
#
# Freeform programming conversion of latch bit
#
PLT01S := RB04 # Set if RB04
PLT01R := RB05 # Reset if RB05
In the output settings, set OUT101 as shown below:
OUT101 := PLT01
Example 13.25 Converting SEL-351 Series Relay Latch Bits (Continued)
