14.9
Date Code 20171006 Instruction Manual SEL-400 Series Relays
ASCII Command Reference
Command Description
CEV NSUM
The CEV NSUM returns the Compressed ASCII event report with no event summary.
CEV S
x
Use the CEV Sx command to specify the sample data resolution of the Com-
pressed ASCII event report. The sample data resolution x can be 4, 8, or 12, depend-
ing on the relay; the default value is 4-samples/cycle if you do not specify Sx. The
Sx option overrides the L option.
CEV TERSE
The CEV TERSE command returns a Compressed ASCII event report without
the event report labels.
Use the TERSE option with any of the CEV commands except CEV ACK.
Ta b l e 1 4.24 C E V N S U M Co m m an d
Command Description Access Level
CEV NSUM Return the most recent event report without the event
summary at full length with 4-samples/cycle data in
Compressed ASCII format.
1, B, P, A, O, 2
CEV n
a
NSUM
a
Parameter
n
indicates event order or serial number; see
CEV on page 14.6
.
Return a particular n event report without the event sum-
mary at full length with 4-samples/cycle data in Com-
pressed ASCII format.
1, B, P, A, O, 2
Ta b l e 1 4.25 C E V S
x
Command
Command Description Access Level
CEV Sx Return the most recent event report at full length with
x-samples/cycle data in Compressed ASCII format.
1, B, P, A, O, 2
CEV n
a
Sx
a
Parameter
n
indicates event order or serial number: see
CEV on page 14.6
.
Return a particular n event report at full length with x-sam-
ples/cycle data in Compressed ASCII format.
1, B, P, A, O, 2
Table 14.26 CEV TERSE Command
Command Description Access Level
CEV TERSE Return the most recent event report at full length with-
out the report labels with 4-samples/cycle data in
Compressed ASCII format.
1, B, P, A, O, 2
CEV n
a
TERSE
a
Parameter
n
indicates event order or serial number.
Return a particular n event report at full length without
the report labels with 4-samples/cycle data in Com-
pressed ASCII format.
1, B, P, A, O, 2
