14.23
Date Code 20171006 Instruction Manual SEL-400 Series Relays
ASCII Command Reference
Command Description
ETH C and ETH R
The ETH C and ETH R commands clear the Ethernet connection statistics.
Option C and R are identical.
When you issue the ETH C and ETH R command, the relay sends the following
prompt:
Are you sure (Y/N)?. If you answer Y <Enter>, the relay clears the
Ethernet statistics and response:
Ethernet Statistics Cleared.
EVENT
Use the EVENT command to view the relay filtered event reports (see Event
Report on page 9.14 for information on event reports).
EVE
The EVE command displays the full-length event reports stored in relay memory.
When parameter n is 1–9999, n indicates the order of the event report. The most
recent event report is 1, the next most recent report is 2, and so on. When param-
eter n is 10000–42767, n indicates the absolute serial number of the event report.
==>>ETH <Enter>
Relay 1 Date: 11/04/2010 Time: 10:22:19.984
Station A Serial Number: 0000000000
MAC 1: 00-30-A7-01-E3-0A
MAC 2: 00-30-A7-01-E3-0B
IP ADDRESS: 10.201.5.27/16
DEFAULT GATEWAY: 10.201.0.1
NETMODE: SWITCHED
PRIMARY 87L PORT: 5A
ACTIVE 87L PORT: 5A
LINK SPEED DUPLEX MEDIA
PORT 5A Down --- --- TX
PORT 5B Down --- --- TX
PORT 5C Up 100M Full TX
PORT 5D Down --- --- TX
PACKETS BYTES ERRORS
SENT RCVD SENT RCVD SENT RCVD
0 8 0 512 0 4
Figure 14.2 Sample ETH Command Response
Table 14.54 ETH C and ETH R Command
Command Description Access Level
ETH C Clears the statistics on Port 5 Ethernet connection 1, B, P, A, O, 2
ETH R Clears the statistics on Port 5 Ethernet connection 1, B, P, A, O, 2
Table 14.55 EVE Command
Command Description Access Level
EVE Return the most recent event report (including settings and
summary) at full length with 4-samples/cycle data.
1, B, P, A, O, 2
EVE n
a
a
Parameter
n
indicates event order or serial number.
Return a particular n event report (including settings and sum-
mary) at full length with 4-samples/cycle data.
1, B, P, A, O, 2
