14.53
Date Code 20171006 Instruction Manual SEL-400 Series Relays
ASCII Command Reference
Command Description
SUM NEXT
Use the SUM N command to view the oldest (next) unacknowledged event summary.
TARGET
The TARGET command displays the elements for a selected row in the Relay
Word bit table.
TAR
Use the TAR command to view a row of Relay Word bit elements or aliases.
When using the TAR command, you can specify the row number or element name.
The relay memorizes the latest target row input conditioned by your present
access level. The relay displays Row 0 if you have not specified a row since the
relay was turned on, the access level has timed out, or you have issued the QUIT
command.
If you specify the repeat count k at a number greater than 8, the relay displays the
repeated target rows on the terminal screen in groups of eight, with the target row
elements listed above each grouping.
TAR ALL
Use the TAR ALL command to display all of the relay targets.
Ta b l e 1 4.1 23 S U M N Com m a n d
Command Description Access Level
SUM N View the oldest unacknowledged event summary at the
present communications port.
1, B, P, A, O, 2
Ta b l e 1 4.1 24 TA R Comm a n d
Command Description Access Level
TAR Display target Row 0 or display the most recently viewed
target row.
1, B, P, A, O, 2
TAR n Display target Row n. 1, B, P, A, O, 2
TAR n k
a
a
Parameter
k
is the repeat count from 1–32767.
Display target Row n and repeat for k times; the repeat
count k must follow the row number.
1, B, P, A, O, 2
TAR name Display the target row with the element name name. 1, B, P, A, O, 2
TAR name k Display the target row with the element name name and
repeat for k times; the repeat count k can be before or
after the name option.
1, B, P, A, O, 2
Table 14.125 TAR ALL Command
Command Description Access Level
TAR ALL Display all target rows. 1, B, P, A, O, 2
