14.56
SEL-400 Series Relays Instruction Manual Date Code 20171006
ASCII Command Reference
Command Description
TEST DB OFF
Use the TEST DB OFF command to end the testing session and remove the
override values. The relay returns the database registers to the pretest values.
TEST DB2
The TEST DB2 command is used to test DNP3 and IEC 61850 MMS communi-
cation protocols.
TEST DB2
Other than Fast Message Protocol, all the communication protocols supported by
the relay (DNP3, IEC 61850, GOOSE) retrieve data from a storage area called
the CADI2 database. These data include both digital quantities and analog quan-
tities. All Relay Word bits along with additional binary input points in DNP3
map are available in CADI2 database as digital quantities.
Use the TEST DB2 command to override any value in the CADI2 database. Val-
ues you enter in the CADI2 database are override values read by the master sta-
tions.
The override value value1 can be logical 0 or logical 1 for digital and status ele-
ments. The analog value2 can be an integer or a floating-point number.
The Relay Word bit TESTDB2 will be asserted while there are points in this test
mode.
Table 14.130 TEST DB OFF Command
Command Description Access Level
TEST DB OFF Clear all override testing values from all virtual devices. B, P, A, O, 2
TEST DB OFF 1 Clear all override testing values from Virtual Device 1
(the relay).
B, P, A, O, 2
TEST DB OFF 1
region
Clear all override testing values from the region region in
Virtual Device 1 (the relay).
B, P, A, O, 2
Table 14.131 TEST DB2 Command
Command Description Access Level
TEST DB2 Display present analog and digital override names and
values.
1, B, P, A, O, 2
TEST DB2 D
name1
a
value1
a
Digital
name1
can be any Relay Word bits or additional binary input points in DNP3 map.
Write the specified override value value1 into the digital
quantity name1.
B, P, A, O, 2
TEST DB2 A
name2
b
value2
b
The analog
name2
is any analog available in the DNP3 reference map and any analog listed as a
data source for IEC 61850 logical devices.
Write the specified override value value2 into the analog
quantity name2.
B, P, A, O, 2
