16.18
SEL-400 Series Relays Instruction Manual Date Code 20171006
DNP3 Communication
DNP3 Documentation
Table 16.9 Relay DNP3 Reference Data Map (Sheet 1 of 2)
Object Label Description
Binary Inputs
01, 02 RLYDIS Relay disabled
01, 02 STFAIL Relay diagnostic failure
01, 02 STWARN Relay diagnostic warning
01, 02 STSET Settings change or relay restart
01, 02 UNRDEV New relay event available
01, 02 NUNREV An unread event exists, newer than the event in the event summary AIs
01, 02 LDATPFW Leading true power factor A-Phase, Terminal W (1 if leading, 0 if lagging or zero)
01, 02 LDBTPFW Leading true power factor B-Phase, Terminal W (1 if leading, 0 if lagging or zero)
01, 02 LDCTPFW Leading true power factor C-Phase, Terminal W (1 if leading, 0 if lagging or zero)
01, 02 LD3TPFW Leading true power factor three-phase, Terminal W (1 if leading, 0 if lagging or zero)
01, 02 Relay Word Relay Word bit label
Binary Outputs
10, 12 RB01–RBnn Remote bits RB01–RBnn
a
10, 12 RB01:RB02
RB03:RB04
RB05:RB06
•
•
•
RB29:RB30
RB31:RBnn
Remote bit pairs RB01–RBnn
a
10, 12 OCm Pulse open Circuit Breaker m command
b
10, 12 CCm Pulse close Circuit Breaker m command
b
10, 12 OCm:CCm Open/close pair for Circuit Breaker m
b
10, 12 89OC01–89OCdd Open Disconnect Switch Control 1–dd
c
10, 12 89CC01–89CCdd Close Disconnect Switch Control 1–dd
c
10, 12 89OC01:89CC01
89OC02:89CC02
89OC03:89CC03
•
•
•
89OCdd:89CCdd
Open/close Disconnect Switch Control Pair 1–dd
c
10, 12 RST_DEM Reset demands
d
10, 12 RST_PDM Reset demand peaks
d
10, 12 RST_ENE Reset energies
d
10, 12 RSTMML Reset min/max metering data for the line
d
10, 12 RSTMMBm Reset min/max metering data for Circuit Breaker m
d
10, 12 RST_BKm Reset Breaker m monitor data
d
10, 12 RST_BAT Reset battery monitor data
d
10, 12 RST_79C Reset recloser shot counter
d
10, 12 RSTFLOC Reset fault location data
d
10, 12 RSTTRGT Reset front-panel targets
d
