17.53
Date Code 20171006 Instruction Manual SEL-400 Series Relays
IEC 61850 Communication
ACSI Conformance Statements
Unbuffered Report Control Block (URCB)
S27 1, 2 Report TP Y
S27–1 1, 2 data-change (dchg) Y
S27–2 1, 2 quality-change (qchg) Y
S27–3 1, 2 data-update (dup)
S28 1, 2 GetURCBValues TP Y
S29 1, 2 SetURCBValues TP Y
Logging
Log Control Block
S30 1, 2 GetLCBValues TP
S31 1, 2 SetLCBValues TP
Log
S32 1, 2 QueryLogByTime TP
S33 1, 2 QueryLogAfter TP
S34 1, 2 GetLogStatusValues TP
Generic Substation Event Model (GSE)
GOOSE
S35 1, 2 SendGOOSEMessage MC Y
GOOSE-CONTROL-BLOCK
S36 1, 2 GetGoReference TP
S37 1, 2 GetGOOSEElementNumber TP
S38 1, 2 GetGoCBValues TP Y
S39 1, 2 SetGoCBValues TP
GSSE
S40 1 SendGSSEMessage MC Deprecated in Edition 2
GSSE-CONTROL-BLOCK
S41 1 GetReference TP Deprecated in Edition 2
S42 1 GetGSSEElementNumber TP Deprecated in Edition 2
S43 1 GetGsCBValues TP Deprecated in Edition 2
S44 1 SetGsCBValues TP Deprecated in Edition 2
Transmission of Sampled Value Model (SVC)
Multicast SV
S45 1, 2 SendMSVMessage MC
Multicast Sampled Value Control Block
S46 1, 2 GetMSVCBValues TP
S47 1, 2 SetMSVCBValues TP
Unicast SV
S48 1, 2 SendUSVMessage TP
Unicast Sampled Value Control Block
S49 1, 2 GetUSVCBValues TP
S50 1, 2 SetUSVCBValues TP
Table 17.29 ACSI Service Conformance Statement (Sheet 2 of 3)
Services AA: TP/MC Client (C) Server (S) Comments
