Schweitzer Engineering Laboratories SEL-421-4 - Page 607

10.23
Date Code 20171021 Instruction Manual SEL-421 Relay
Communications Interfaces
IEC 61850 Communication
BFR1RBRF1 OpIn.phsB RTB1
a
Circuit Breaker 1 B-Phase retrip
BFR1RBRF1 OpIn.phsC RTC1
a
Circuit Breaker 1 C-Phase retrip
BFR1RBRF1 Str.general CSV02 BFI3P1 OR BFIA1 OR BFIB1 OR BFIC1
BFR2RBRF2 OpEx.general FBF2
a
Circuit Breaker 2 circuit breaker failure
BFR2RBRF2 OpEx.phsA FBFA2
a
Circuit Breaker 2 A-Phase circuit breaker failure
BFR2RBRF2 OpEx.phsB FBFB2
a
Circuit Breaker 2 B-Phase circuit breaker failure
BFR2RBRF2 OpEx.phsC FBFC2
a
Circuit Breaker 2 C-Phase circuit breaker failure
BFR2RBRF2 OpIn.general RT2
a
Circuit Breaker 2 retrip
BFR2RBRF2 OpIn.phsA RTA2
a
Circuit Breaker 2 A-Phase retrip
BFR2RBRF2 OpIn.phsB RTB2
a
Circuit Breaker 2 B-Phase retrip
BFR2RBRF2 OpIn.phsC RTC2
a
Circuit Breaker 2 C-Phase retrip
BFR2RBRF2 Str.general CSV03 BFI3P2 OR BFIA2 OR BFIB2 OR BFIC2
BK1AXCBR1 Pos.stVal 52ACL1?1:2
a
Circuit Breaker 1, Pole A closed
BK1BXCBR2 Pos.stVal 52BCL1?1:2
a
Circuit Breaker 1, Pole B closed
BK1CXCBR3 Pos.stVal 52CCL1?1:2
a
Circuit Breaker 1, Pole C closed
BK2AXCBR4 Pos.stVal 52ACL2?1:2
a
Circuit Breaker 2, Pole A closed
BK2BXCBR5 Pos.stVal 52BCL2?1:2
a
Circuit Breaker 2, Pole B closed
BK2CXCBR6 Pos.stVal 52CCL2?1:2
a
Circuit Breaker 2, Pole C closed
BKR1CSWI1 OpCls.general CC1
a
Circuit Breaker 1 close command
BKR1CSWI1 OpOpn.general OC1
a
Circuit Breaker 1 open command
BKR1CSWI1 Pos.stVal 52ACL1?1:2
a
Circuit Breaker 1, Pole A closed
BKR1PTRC2 Tr.general CSV06 TPA1 OR TPB1 OR TPC1
BKR1PTRC2 Tr.phsA TPA1
a
Circuit Breaker 1 Trip A
BKR1PTRC2 Tr.phsB TPB1
a
Circuit Breaker 1 Trip B
BKR1PTRC2 Tr.phsC TPC1
a
Circuit Breaker 1 Trip C
BKR2CSWI2 OpCls.general CC2
a
Circuit Breaker 2 close command
BKR2CSWI2 OpOpn.general OC2
a
Circuit Breaker 2 open command
BKR2CSWI2 Pos.stVal 52ACL2?1:2
a
Circuit Breaker 2, Pole A closed
BKR2PTRC3 Tr.general CSV07 TPA2 OR TPB2 OR TPC2
BKR2PTRC3 Tr.phsA TPA2
a
Circuit Breaker 2 Trip A
BKR2PTRC3 Tr.phsB TPB2
a
Circuit Breaker 2 Trip B
BKR2PTRC3 Tr.phsC TPC2
a
Circuit Breaker 2 Trip C
DC10CSWI10 OpCls.general 89CC10
a
ASCII Close Disconnect 10 command
DC10CSWI10 OpOpn.general 89OC10
a
ASCII Open Disconnect 10 command
DC10CSWI10 Pos.stVal 89CL10|89OPN10?0:1:2:3
a
Disconnect 10 status
DC1CSWI1 OpCls.general 89CC01
a
ASCII Close Disconnect 1 command
DC1CSWI1 OpOpn.general 89OC01
a
ASCII Open Disconnect 1 command
DC1CSWI1 Pos.stVal 89CL01|89OPN01?0:1:2:3
a
Disconnect 1 status
DC2CSWI2 OpCls.general 89CC02
a
ASCII Close Disconnect 2 command
DC2CSWI2 OpOpn.general 89OC02
a
ASCII Open Disconnect 2 command
DC2CSWI2 Pos.stVal 89CL02|89OPN02?0:1:2:3
a
Disconnect 2 status
Table 10.15 Logical Device: PRO (Protection) (Sheet 2 of 6)
Logical Node Attribute Data Source Comment
