Schweitzer Engineering Laboratories SEL-421-4 - Page 612

10.28
SEL-421 Relay Instruction Manual Date Code 20171021
Communications Interfaces
IEC 61850 Communication
METMMXU1 A1.phsB.instCVal.mag.f LIBFM 10-cycle average fundamental B-Phase current (magnitude)
METMMXU1 A1.phsC.instCVal.ang.f LICFA 10-cycle average fundamental C-Phase current (angle)
METMMXU1 A1.phsC.instCVal.mag.f LICFM 10-cycle average fundamental C-Phase current (magnitude)
METMMXU1 A2.phsA.instCVal.ang.f B1IAFA 10-cycle average fundamental A-Phase current angle (Breaker 1)
METMMXU1 A2.phsA.instCVal.mag.f B1IAFM 10-cycle average fundamental A-Phase current magnitude
(Breaker 1)
METMMXU1 A2.phsB.instCVal.ang.f B1IBFA 10-cycle average fundamental B-Phase current angle (Breaker 1)
METMMXU1 A2.phsB.instCVal.mag.f B1IBFM 10-cycle average fundamental B-Phase current magnitude
(Breaker 1)
METMMXU1 A2.phsC.instCVal.ang.f B1ICFA 10-cycle average fundamental C-Phase current angle (Breaker 1)
METMMXU1 A2.phsC.instCVal.mag.f B1ICFM 10-cycle average fundamental C-Phase current magnitude
(Breaker 1)
METMMXU1 A3.phsA.instCVal.ang.f B2IAFA 10-cycle average fundamental A-Phase current angle (Breaker 2)
METMMXU1 A3.phsA.instCVal.mag.f B2IAFM 10-cycle average fundamental A-Phase current magnitude
(Breaker 2)
METMMXU1 A3.phsB.instCVal.ang.f B2IBFA 10-cycle average fundamental B-Phase current angle (Breaker 2)
METMMXU1 A3.phsB.instCVal.mag.f B2IBFM 10-cycle average fundamental B-Phase current magnitude
(Breaker 2)
METMMXU1 A3.phsC.instCVal.ang.f B2ICFA 10-cycle average fundamental C-Phase current angle (Breaker 2)
METMMXU1 A3.phsC.instCVal.mag.f B2ICFM 10-cycle average fundamental C-Phase current magnitude
(Breaker 2)
METMMXU1 Hz.instMag.f FREQ Tracking frequency
METMMXU1 PF.phsA.instCVal.mag.f DPFA A-Phase displacement power factor
METMMXU1 PF.phsB.instCVal.mag.f DPFB B-Phase displacement power factor
METMMXU1 PF.phsC.instCVal.mag.f DPFC C-Phase displacement power factor
METMMXU1 PhV.phsA.instCVal.ang.f VAFA A-Phase 10-cycle average fundamental phase voltage angle
METMMXU1 PhV.phsA.instCVal.mag.f VAFM A-Phase 10-cycle average fundamental phase voltage magnitude
METMMXU1 PhV.phsB.instCVal.ang.f VBFA B-Phase 10-cycle average fundamental phase voltage angle
METMMXU1 PhV.phsB.instCVal.mag.f VBFM B-Phase 10-cycle average fundamental phase voltage magnitude
METMMXU1 PhV.phsC.instCVal.ang.f VCFA C-Phase 10-cycle average fundamental phase voltage angle
METMMXU1 PhV.phsC.instCVal.mag.f VCFM C-Phase 10-cycle average fundamental phase voltage magnitude
METMMXU1 TotPF.instMag.f 3DPF Three-phase displacement power factor
METMMXU1 TotVA.instMag.f 3S_F Fundamental apparent three-phase power
METMMXU1 TotVAr.instMag.f 3Q_F Fundamental reactive three-phase power
METMMXU1 TotW.instMag.f 3P_F Fundamental real three-phase power
METMMXU1 VAr.phsA.instCVal.mag.f QA_F A-Phase fundamental reactive power
METMMXU1 VAr.phsB.instCVal.mag.f QB_F B-Phase fundamental reactive power
METMMXU1 VAr.phsC.instCVal.mag.f QC_F C-Phase fundamental reactive power
METMMXU1 W.phsA.instCVal.mag.f PA_F A-Phase fundamental real power
METMMXU1 W.phsB.instCVal.mag.f PB_F B-Phase fundamental real power
METMMXU1 W.phsC.instCVal.mag.f PC_F C-Phase fundamental real power
PKDMDMDST1 A.phsA.instCVal.mag.f IAPKD Peak demand A-Phase current
PKDMDMDST1 A.phsB.instCVal.mag.f IBPKD Peak demand B-Phase current
Table 10.16 Logical Device: MET (Metering) (Sheet 2 of 3)
Logical Node Attribute Data Source Comment
