Relay Word Bits
Alphabetical List
89BM03 Disconnect 3 N/C auxiliary contact 334
89BM04 Disconnect 4 N/C auxiliary contact 335
89BM05 Disconnect 5 N/C auxiliary contact 336
89BM06 Disconnect 6 N/C auxiliary contact 337
89BM07 Disconnect 7 N/C auxiliary contact 338
89BM08 Disconnect 8 N/C auxiliary contact 339
89BM09 Disconnect 9 N/C auxiliary contact 340
89BM10 Disconnect 10 N/C auxiliary contact 341
89CBL01 Disconnect 01 close block 364
89CBL02 Disconnect 02 close block 366
89CBL03 Disconnect 03 close block 368
89CBL04 Disconnect 04 close block 370
89CBL05 Disconnect 05 close block 372
89CBL06 Disconnect 06 close block 374
89CBL07 Disconnect 07 close block 376
89CBL08 Disconnect 08 close block 378
89CBL09 Disconnect 09 close block 380
89CBL10 Disconnect 10 close block 382
89CC01 ASCII Close Disconnect 1 command 344
89CC02 ASCII Close Disconnect 2 command 346
89CC03 ASCII Close Disconnect 3 command 348
89CC04 ASCII Close Disconnect 4 command 350
89CC05 ASCII Close Disconnect 5 command 352
89CC06 ASCII Close Disconnect 6 command 354
89CC07 ASCII Close Disconnect 7 command 356
89CC08 ASCII Close Disconnect 8 command 358
89CC09 ASCII Close Disconnect 9 command 360
89CC10 ASCII Close Disconnect 10 command 362
89CCM01 Mimic Disconnect 1 close control 344
89CCM02 Mimic Disconnect 2 close control 346
89CCM03 Mimic Disconnect 3 close control 348
89CCM04 Mimic Disconnect 4 close control 350
89CCM05 Mimic Disconnect 5 close control 352
89CCM06 Mimic Disconnect 6 close control 354
89CCM07 Mimic Disconnect 7 close control 356
89CCM08 Mimic Disconnect 8 close control 358
89CCM09 Mimic Disconnect 9 close control 360
89CCM10 Mimic Disconnect 10 close control 362
89CCN01 Close Disconnect 1 344
89CCN02 Close Disconnect 2 346
89CCN03 Close Disconnect 3 348
Table 11.1 Alphabetic List of Relay Word Bits (Sheet 7 of 34)
Name Description Row
