Relay Word Bits
Alphabetical List
AST09Q–AST16Q Automation Sequencing Timer 9–16 output 187
AST17Q–AST24Q Automation Sequencing Timer 17 output 188
AST25Q–AST32Q Automation Sequencing Timer 25–32 output 189
AST01R–AST08R Automation Sequencing Timer 1–8 reset 190
AST09R–AST16R Automation Sequencing Timer 9–16 reset 191
AST17R–AST24R Automation Sequencing Timer 17 reset 192
AST25R–AST32R Automation Sequencing Timer 25–32 reset 193
ASV001–ASV008 Automation SEL
OGIC Vari a ble 1 – 8 15 0
ASV009–ASV016 Automation SEL
OGIC Variable 9–16 151
ASV017–ASV024 Automation SEL
OGIC Variable 17–24 152
ASV025–ASV032 Automation SEL
OGIC Variable 25–32 153
ASV033–ASV040 Automation SEL
OGIC Variable 33–40 154
ASV041–ASV048 Automation SEL
OGIC Variable 41–48 155
ASV049–ASV056 Automation SEL
OGIC Variable 49–56 156
ASV057–ASV064 Automation SEL
OGIC Variable 57–64 157
ASV065–ASV072 Automation SEL
OGIC Variable 65–72 158
ASV073–ASV080 Automation SEL
OGIC Variable 73–80 159
ASV081–ASV088 Automation SEL
OGIC Variable 81–88 160
ASV089–ASV096 Automation SEL
OGIC Variable 89–96 161
ASV097–ASV104 Automation SEL
OGIC Variable 97–104 162
ASV105–ASV112 Automation SEL
OGIC Variable 105–112 163
ASV113–ASV120 Automation SEL
OGIC Variable 113–120 164
ASV121–ASV128 Automation SEL
OGIC Variable 121–128 165
ASV129–ASV136 Automation SEL
OGIC Variable 129–136 166
ASV137–ASV144 Automation SEL
OGIC Variable 137–144 167
ASV145–ASV152 Automation SEL
OGIC Variable 145–152 168
ASV153–ASV160 Automation SEL
OGIC Variable 153–160 169
ASV161–ASV168 Automation SEL
OGIC Variable 161–168 170
ASV169–ASV176 Automation SEL
OGIC Variable 169–176 171
ASV177–ASV184 Automation SEL
OGIC Variable 177–184 172
ASV185–ASV192 Automation SEL
OGIC Variable 185–192 173
ASV193–ASV200 Automation SEL
OGIC Variable 193–200 174
ASV201–ASV208 Automation SEL
OGIC Variable 201–208 175
ASV209–ASV216 Automation SEL
OGIC Variable 209–216 176
ASV217–ASV224 Automation SEL
OGIC Variable 217–224 177
ASV225–ASV232 Automation SEL
OGIC Variable 225–232 178
ASV233–ASV240 Automation SEL
OGIC Variable 233–240 179
ASV241–ASV248 Automation SEL
OGIC Variable 241–248 180
ASV249–ASV256 Automation SEL
OGIC Variable 249–256 181
ATPA–ATPC Assert Trip A–Trip C 54
AUNRLBL Automation SELOGIC control equation unresolved label 204
Table 11.1 Alphabetic List of Relay Word Bits (Sheet 13 of 34)
Name Description Row
