5.41
Date Code 20171006 Instruction Manual SEL-400 Series Relays
Control
Bay Control Example Application
Table 5.6 Application Example Bay Control Settings for Bus 1, Bus 2, and
Transfer Bus Bay With Ground Switch Application (Sheet 1 of 2)
Setting Description Entry
General One-Line Settings
MIMIC One-line Screen Number (1–999) 4
BAYNAME Bay Name (20 characters) BAY CONTROL
Busbar Information
BUSNAM1 Busbar 1 Name (40 pixels, 6–10 characters) Bus T
BUSNAM2 Busbar 2 Name (40 pixels, 6–10 characters) Bus 2
BUSNAM3 Busbar 3 Name (40 pixels, 6–10 characters) Bus 1
Breaker Information
B1HMINM Breaker 1 HMI Name (max 3–17 characters) Bkr 1
B1CTLNM Breaker 1 HMI Cntl Scr. Name (max. 15 characters) Bkr 1
521CLSM Breaker 1 Close Status (SEL
OGIC Equation) 52ACL1
521_ALM Breaker 1 Alarm Status (SEL
OGIC Equation) 52AAL1
Disconnect Information
D1HMIN Disconnect 1 HMI Name (max 3–17 characters) D1
D1CTLN Disconnect 1 Name (25 pixels, max. 15 characters) Dis 1
89AM1 Disconnect 1 N/O Contact (SELOGIC Equation) IN103
89BM1 Disconnect 1 N/C Contact (SEL
OGIC Equation) IN104
89ALP1 Disconnect 1 Alarm Pickup Delay (1–99999 cyc) 260
89CCN1 Disconnect 1 Close Control (SEL
OGIC Equation) 89CC01
89OCN1 Disconnect 1 Open Control (SEL
OGIC Equation) 89OC01
89CST1 Disconnect 1 Close Seal-in Time (1–99999 cyc) 280
89OST1 Disconnect 1 Open Seal-in Time (1–99999 cyc) 280
D2HMIN Disconnect 2 HMI Name (max. 3–17 characters) D2
D2CTLN Disconnect 2 Name (25 pixels, 4–6 characters) Dis 2
89AM2 Disconnect 2 N/O Contact (SEL
OGIC Equation) 1
89BM2 Disconnect 2 N/C Contact (SEL
OGIC Equation) 0
89ALP2 Disconnect 2 Alarm Pickup Delay (1–99999 cyc) 260
89CCN2 Disconnect 2 Close Control (SEL
OGIC Equation) 89CC02
89OCN2 Disconnect 2 Open Control (SEL
OGIC Equation) 89OC02
89CST2 Disconnect 2 Close Seal-in Time (1–99999 cyc) 280
89OST2 Disconnect 2 Open Seal-in Time (1–99999 cyc) 280
D3HMIN Disconnect 3 HMI Name (max. 3–17 characters) D3
D3CTLN Disconnect 3 Name (25 pixels, 4–6 characters) Dis 3
89AM3 Disconnect 3 N/O Contact (SEL
OGIC Equation) 1
89BM3 Disconnect 3 N/C Contact (SEL
OGIC Equation) 0
89ALP3 Disconnect 3 Alarm Pickup Delay (1–99999 cyc) 260
89CCN3 Disconnect 3 Close Control (SEL
OGIC Equation) 89CC03
89OCN3 Disconnect 3 Open Control (SEL
OGIC Equation) 89OC03
89CST3 Disconnect 3 Close Seal-in Time (1–99999 cyc) 280
89OST3 Disconnect 3 Open Seal-in Time (1–99999 cyc) 280
