Control
Bay Control Example Application
STA_BAT Station Battery Screen N
FUND_VI Fundamental Voltage and Current Screen N
FUNDSEQ Fundamental Sequence Quantities Screen N
FUND_BK Fundamental Breaker Currents Screen N
ONELINE One-Line Bay Control Diagram Y
Selectable Operator Pushbuttons
PB2_HMI Pushbutton 2 HMI Screen BC
Table 5.8 Application Example Output Settings, Output SEL
OGIC Control Equations
Setting Description Entry
OUT103 OUT103 SELOGIC control equation 89CLS1 AND NOT 52CLSM1
OUT104 OUT104 SEL
OGIC control equation 89OPEN1 AND NOT 52CLSM1
OUT105 OUT105 SEL
OGIC control equation 89CLS2 AND NOT 52CLSM1
OUT106 OUT106 SEL
OGIC control equation 89OPEN2 AND NOT 52CLSM1
OUT201 OUT201 SEL
OGIC control equation 89CLS3 AND 89OPN5
OUT202 OUT202 SEL
OGIC control equation 89OPEN3 AND 52CLSM1
OUT203 OUT203 SEL
OGIC control equation 89CLS4 AND NOT 52CLSM1
OUT204 OUT204 SEL
OGIC control equation 89OPEN4 AND NOT 52CLSM1
OUT205 OUT205 SEL
OGIC control equation 89CLS5 AND NOT 52CLSM1
OUT206 OUT206 SEL
OGIC control equation 89OPEN5 AND NOT 52CLSM1
