Parameters Description Unit
F2 Feedrate for approach to the second position
Alternatively, rapid traverse
mm/min
X2 2nd position ∅ (abs) or 2nd position (inc) mm
Z2 2nd position (abs or inc) mm
F3 Feedrate to approach the third position
Alternatively, rapid traverse
mm/min
X3 3rd position ∅ (abs) or 3rd position (inc) mm
Z3 3rd position (abs or inc) mm
Tool change WkzWpkt: Approach the tool change point from the last programmed position and
carry out a tool change
Direct: Tool is not changed at the tool change position, but at the last programmed
position
No: Tool is not changed
T Tool name - (only for "direct" tool change)
D Cutting edge number - (only for "direct" tool change)
F4 Feedrate for approach to the fourth position
Alternatively, rapid traverse
mm/min
X4 4th position ∅ (abs) or 4th position (inc) mm
Z4 4th position (abs or inc) mm
F5 Feedrate to approach the fifth position
Alternatively, rapid traverse
mm/min
X5 5st position ∅ (abs) or 5th position (inc) mm
Z5 5th position (abs or inc) mm
F6 Feedrate to approach the sixth position
Alternatively, rapid traverse
mm/min
X6 6th position ∅ (abs) or 6th position (inc) mm
Z6 6th position (abs or inc) mm
Creating a ShopTurn program
9.16 Programming the approach/retraction cycle
Turning
Operating Manual, 06/2019, A5E44903486B AB 323
