7. Press the <CYCLE START> key.
The tool is automatically swung into the machining position and the name
of the tool displayed in the tool status bar.
5.2.3 Starting and stopping the spindle manually
Procedure
1. Select the "T,S,M" softkey in the "JOG" mode.
2. Select the desired spindle (e.g. S1) and enter the desired spindle speed
or cutting speed in the right-hand entry field.
3. If the machine has a gearbox for the spindle, set the gearing step.
4 Select a spindle direction of rotation (clockwise or counterclockwise) in
the "Spindle M function" field.
5. Press the <CYCLE START> key.
The spindle rotates.
6. Select the "Stop" setting in the "Spindle M function" field.
Press the <CYCLE START> key.
The spindle stops.
Note
Changing the spindle speed
If you enter the speed in the "Spindle" field while the spindle is rotating, the new speed is
applied.
Working in manual mode
5.2 Selecting a tool and spindle
Turning
140 Operating Manual, 06/2019, A5E44903486B AB
