11.2.5.2 Editing a G code multi-channel program
Editing a G code multi-channel program
Precondition
● The "programSYNC" option is set.
● In order to display the machining at the counterspindle at the correct position in the
simulation, the linear axis of the counterspindle must be positioned before CYCLE208
(multi-channel data).
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Procedure
1. Position the cursor in the "Workpieces" folder on a job list and press the
"Open" softkey.
Note:
If the cursor is located on a workpiece, then a search is made for a job list
with the same name.
The "Job list ..." window opens and the program assignment to the chan‐
nels is displayed.
2. Press the "OK" softkey.
The programs are displayed next to one another in the editor.
3. Position the cursor on the first block of the program (multi-channel data)
and press the <Cursor right> key.
The parameter screen "Multi-channel data" is opened.
4. Enter the required values if you wish to change cross-channel data.
Adding multi-channel data in a G code program
You have the possibility of adding the multi-channel cycle (CYCLE208) subsequently.
Procedure
1. The double editor is opened and the cursor is positioned in the G
code program.
2. Press the "Misc." and "Multi-channel data" softkeys.
The "Call multi-channel data" input window opens.
A field for specifying the job list appears.
This field is read-only.
Multi-channel machining
11.2 Multi-channel support
Turning
Operating Manual, 06/2019, A5E44903486B AB 675
