Call live streaming
You have the following options for calling live streaming:
● By clicking the "Camera" softkey in the "Machine" operating area
● By clicking the "Camera" softkey in the "Set up" operating area
● Via the "Camera 1" and "Camera 2" widgets in the sidescreen
● Via the "Camera 1" and "Camera 2" widgets in the Display Manager (840D sl only)
The live streaming is displayed in the first-called window.
To switch between the calling windows, live streaming must be restarted.
Note
As long as the "Camera configuration" window is open, live streaming can only be started from
this window.
2.4.17 Online help in SINUMERIK Operate
A comprehensive context-sensitive online help is stored in the control system.
● A brief description is provided for each window and, if required, step-by-step instructions for
the operating sequences.
● A detailed help is provided in the editor for every entered G code. You can also display all
G functions and take over a selected command directly from the help into the editor.
● A help page with all parameters is provided on the input screen in the cycle programming.
● Lists of the machine data
● Lists of the setting data
● Lists of the drive parameters
● List of all alarms
Procedure
Calling context-sensitive online help
1. You are in an arbitrary window of an operating area.
2. Press the <HELP> key or on an MF2 keyboard, the <F12> key.
The help page of the currently selected window is opened in a subscreen.
3. Press the "Full screen" softkey to use the entire user interface for the
display of the online help.
Press the "Full screen" softkey again to return to the subscreen.
Introduction
2.4 User interface
Turning
Operating Manual, 06/2019, A5E44903486B AB 67
