Machine manufacturer
Please refer to the machine manufacturer's specifications.
10.3.13 Plunge-turning rest (CYCLE952)
Function
The "Plunge turning residual material" function is used when you want to machine the material
that remained after plunge turning.
For plunge turning ShopTurn, the cycle automatically detects any residual material and
generates an updated blank contour. For a G code program, the function must have been
previously selected in the screen. Material that remains as part of the finishing allowance is not
residual material. The "Plunge turning residual material" function allows you to remove
unwanted material with a suitable tool.
Software option
To machine residual material, you require the "Residual material detection and
machining" option.
Procedure
1. The part program or ShopTurn program to be processed has been cre‐
ated and you are in the editor.
2. Press the "Contour turning" softkey.
3. Press the "Plunge turning residual material" softkey.
The "Plunge turning residual material" input window opens.
G code program parameters ShopTurn program parameters
PRG
● Name of the program to be generated
● Auto
Automatic generation of program names
T Tool name
PL Machining plane D Cutting edge number
RP Retraction plane – (only for
longitudinal machining direc‐
tion)
mm F Feedrate mm/rev
Programming technology functions (cycles)
10.3 Contour turning
Turning
482 Operating Manual, 06/2019, A5E44903486B AB
