16.6 More complex machining
The following functions are available to you for comprehensive machining in manual mode:
● Drilling (center drilling, centering, drilling, reaming, deep-drilling, threads, positions)
● Turning (stock removal, groove, undercut, threads, tapping)
● Milling (face milling, pocket, spigot, multiple edge, groove, thread milling, engraving)
● Contour turning (contour, stock removal, grooving, plunge turning)
Note
Deselecting technological functions
Press the "Back" softkey to return to the main screen from the list of technological functions.
General sequence
For more complex machining processes, proceed in the following order:
● Select the desired function via the corresponding softkey.
● Select the tool and enter the desired values in the parameter screen.
● Press the "Accept" softkey to save the values.
The input screen form closes.
A line with the specified parameters is displayed on the basic screen.
● Press the <CYCLE START> key.
The selected cycle is started.
- OR -
● Press the "Cancel" softkey to return to the basic screen.
Note
Note
You can return to the parameter screen form at any time to check and correct the inputs.
Press the <"Cursor right> key to jump back to the input screen form.
Working with Manual Machine
16.6 More complex machining
Turning
Operating Manual, 06/2019, A5E44903486B AB 867
