Parameter Description Unit
X0
Y0
Z0
Y1 ...Y7
Z1 ...Z7 (on‐
ly for ShopTurn)
Peripheral surface C - at right angles
Cylinder diameter ∅ (abs)
Y coordinate of 1st position (abs)
Z coordinate of 1st position (abs)
Y coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated
Z coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated
mm
mm
mm
mm
mm
C0
Z0
C1 ...C7
Z1 ... Z7 (on‐
ly for ShopTurn)
Peripheral surface C - cylindrical
C coordinate of 1st position (abs)
1st position of hole with reference to Z axis (abs)
C coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated
Additional positions in the Z axis (abs or inc)
Incremental dimension: The sign is also evaluated
Degrees
mm
Degrees
mm
X0
C0
Y0
Z0
Y1 ...Y7
Z1 ...Z7 (on‐
ly for ShopTurn
Peripheral surface Y:
Reference point in X direction (abs)
Positioning angle for machining surface
Y coordinate of 1st position (abs)
Z coordinate of 1st position (abs)
Y coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated
Z coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated
mm
Degrees
mm
mm
mm
mm
10.1.12 Row position pattern (HOLES1)
Function
You can program any number of positions at equal distances along a line using the "Row
position pattern" function.
