Parameter Description Unit
X0
Y0
X1 ...X8
Y1 ...Y8
(only for G code)
Axes XY (at right angles)
X coordinate of 1st position (abs)
Y coordinate of 1st position (abs)
X coordinate for additional positions (abs or inc)
Y coordinate for additional positions (abs or inc)
mm
mm
mm
mm
Z0
C0
Z1 ... Z8
C1 ... C8
(only for G code)
Axes ZC (for G19)
Z coordinate of 1st position (abs)
C coordinate of 1st position (abs)
Z coordinates for additional positions (abs or inc)
C coordinates for additional positions (abs or inc)
mm
Degrees
mm
Degrees
Y0
Z0
C0
Y1 ... Y5
Z1 ... Z5
C1 ...C5
(only for G code)
Axes YZC (for G19)
Y coordinate of 1st position (abs)
Z coordinate of 1st position (abs)
C coordinate of 1st position
Y coordinates of additional positions (abs or inc)
Z coordinates for additional positions (abs or inc)
C coordinates for additional positions (abs or inc)
mm
mm
Degrees
mm
mm
Degrees
Z0
CP
X0
Y0
X1 ... X7
Y1 ... Y7
(only for Shop‐
Turn)
Face C and face Y - at right angles
Z coordinate of the reference point (abs)
Positioning angle for machining area (only for face Y)
Angle CP does not have any effect on the machining position in relation to the workpiece.
It is only used to position the workpiece with the rotary axis C in such a way that machining
is possible on the machine.
X coordinate of 1st position (abs)
Y coordinate of 1st position (abs)
X coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated
Y coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated
mm
Degrees
mm
mm
mm
mm
Z0
CP
C0
L0
C1 ... C7
L1 ... L7 (on‐
ly for ShopTurn)
Face C and face Y - polar (ShopTurn:
Z coordinate of the reference point (abs)
Positioning angle for machining area (only for face Y)
Angle CP does not have any effect on the machining position in relation to the workpiece.
It is only used to position the workpiece with the rotary axis C in such a way that machining
is possible on the machine.
C coordinate of 1st position (abs)
1st position of hole with reference to Y axis (abs)
C coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated
Distance to position (abs or inc)
Incremental dimension: The sign is also evaluated
mm
Degrees
Degrees
mm
Degrees
mm
Programming technology functions (cycles)
10.1 Drilling
Turning
Operating Manual, 06/2019, A5E44903486B AB 389
