Parameters Description Unit
Selection - (not for
table "Without")
Selection, table value: e.g.
M3; M10; etc. (ISO metric)
W3/4"; etc. (Whitworth BSW)
G3/4"; etc. (Whitworth BSP)
N1" - 8 UNC; etc. (UNC)
P
- (selection
only possible for
"Table
without selection")
Pitch ...
in MODULUS: MODULUS = Pitch/π
in turns per inch: Used with pipe threads, for example.
When entered per inch, enter the integer number in front of the decimal point in the
first parameter field and the figures after the decimal point as a fraction in the second
and third field.
in mm/rev
in inch/rev
The pitch is determined by the tool used.
MODULUS
Turns/"
mm/rev
in/rev
Z2 Retraction amount before thread milling
The thread depth in the direction of the tool axis is defined using Z2. Z2 is relative to the
tool tip.
mm
Nominal diameter mm
Milling direction
Climbing: Mill thread in one cycle.
Conventional: Mill thread in one cycle.
Climbing - conventional: Mill thread in two cycles: rough cutting is performed by
conventional milling with defined allowances, then finish cutting is performed with
climb milling with milling feedrate FS.
FS Finishing feedrate rate - (only for climbing - conventional milling) mm/min
mm/tooth
10.1.10 Positions and position patterns
Function
Arbitrary positions
Position on a line, on a grid or frame
Position on a full or pitch circle
Programming technology functions (cycles)
10.1 Drilling
Turning
384 Operating Manual, 06/2019, A5E44903486B AB
