3.5.3 Standard widgets
Open sidescreen
● Tap the arrow on the navigation bar to show the sidescreen.
The standard widgets are displayed in minimized form as the header line.
① Widget header lines
② Arrow key for showing/hiding the sidescreen
Navigating in sidescreen
● To scroll through the list of widgets, swipe vertically with 1 finger.
- OR -
● To return to the end or to the beginning of the list of widgets, swipe vertically with 3 fingers.
Open widgets
● To open a widget, tap the header line of the widget.
3.5.4 "Actual value" widget
The widget contains the position of the axes in the displayed coordinate system.
The distance-to-go for the current NC block is displayed while a program is running.
Multitouch operation with SINUMERIK Operate
3.5 Expansion with side screen
Turning
Operating Manual, 06/2019, A5E44903486B AB 81
