If you want to rework some threads, input the initial plunge depth D0 (inc.). This is the depth that
was reached during a previous machining.
Note
By inputting the plunge depth, you avoid unnecessary idle cuts when reworking the threads.
B axis
16.6.3 Contour turning with Manual machine
For contour turning of simple geometric shapes, the same range of technological functions
(cycles) as in automatic mode is available.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
⇒ ⇒
Parameters
The parameters of the input screen forms correspond to the parameters under Automatic (see
Section Contour turning (Page 442)).
Last contour
If you have created a contour since the startup of the machine, the "Last con‐
tour" softkey is available. You then have the option to reopen the input screen
with the last contour you entered in "Manual machine" for editing.
Working with Manual Machine
16.6 More complex machining
Turning
Operating Manual, 06/2019, A5E44903486B AB 871
