Page #143 background image
Note
When the controller is switched on, the axes can be traversed right up to the limits of the
machine as the reference points have not yet been approached and the axes referenced.
Emergency limit switches might be triggered as a result.
The software limit switches and the working area limitation are not yet operative!
The feed enable signal must be set.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
5.3.2 Traversing axes by a variable increment
Procedure
1. Select the "Machine" operating area.
2. Press the <JOG> key.
3. Press the "Settings" softkey.
The "Settings for Manual Operation" window is opened.
4. Enter the desired value for the "Variable increment" parameter.
Example: Enter 500 for a desired increment of 500 μm (0.5 mm).
5. Press the <Inc VAR> key.
6. Select the axis to be traversed.
7. Press the <+> or <-> key.
Each time you press the key the selected axis is traversed by the set
increment.
Feedrate and rapid traverse override switches can be operative.
Working in manual mode
5.3 Traversing axes
Turning
Operating Manual, 06/2019, A5E44903486B AB 143
