5.2.4 Positioning the spindle
Procedure
1. Select the "T,S,M" softkey in the "JOG" mode.
2. Select the "Stop Pos." setting in the "Spindle M function" field.
The "Stop Pos." entry field appears.
3. Enter the desired spindle stop position.
The spindle position is specified in degrees.
4. Press the <CYCLE START> key.
The spindle is moved to the desired position.
Note
You can use this function to position the spindle at a specific angle, e.g. during a tool change.
● A stationary spindle is positioned via the shortest possible route.
● A rotating spindle is positioned as it continues to turn in the same direction.
Working in manual mode
5.2 Selecting a tool and spindle
Turning
Operating Manual, 06/2019, A5E44903486B AB 141
