Parameter Description Unit
Contour selection
● Contour name
● Labels
● Subprogram
● Labels in the subprogram
Contour name CON: Contour name
Labels
● LAB1: Label 1
● LAB2: Label 2
Subprogram PRG: Subprogram
Labels in the subpro‐
gram
● PRG: Subprogram
● LAB1: Label 1
● LAB2: Label 2
Note
EXTCALL / EES
When calling a part program via EXTCALL without EES, the contour can only be called via
“Contour name” and/or “Labels”. This is monitored in the cycle, which means that contour calls
via "subprogram" or "labels in subprogram" are only possible if EES is active.
10.3.8 Stock removal (CYCLE952)
Function
You can use the "Stock removal" function to machine contours in the longitudinal or transverse
direction or parallel to the contour.
Blank
For stock removal, the cycle takes into account a blank that can comprise a cylinder, an
allowance on the finished-part contour or any blank contour. You must define a blank contour
as a separate closed contour in advance of the finished-part contour.
Note
In order to avoid collisions between tools and workpieces due to positioning motions, the
programmed blank contour must match the real blank.
If the blank and finished-part contours do not intersect, the cycles defines the boundary
between blank and finished part. If the angle between the straight line and the Z axis is greater
than 1°, the boundary is placed at the top - and if the angle is less than or equal to 1°, the
boundary is placed at the side.
Programming technology functions (cycles)
10.3 Contour turning
Turning
Operating Manual, 06/2019, A5E44903486B AB 455
