3.5 Expansion with side screen
3.5.1 Overview
Panels in widescreen format provide the possibility of using the extra area to display additional
elements. In addition to the SINUMERIK Operate screen, displays and virtual keys are shown
to provide faster information and operation.
This sidescreen must be activated. To do this, a navigation bar is displayed.
You can display the following elements above the navigation bar:
● Displaying (widgets)
● Virtual keys (pages)
– ABC keyboard
– MCP keys
Machine manufacturer
Please observe the information provided by the machine manufacturer.
Requirements
● A widescreen format multitouch panel (e.g. OP 015 black) is required to display widgets and
pages.
● It is only possible to activate and configure a sidescreen when using the "SINUMERIK
Operate Generation 2" user interface.
References
For information on activating the sidescreen and to configure the virtual keys, refer to the
following literature:
● SINUMERIK Operate (IM9) / SINUMERIK 840D sl Commissioning Manual
3.5.2 Sidescreen with standard windows
When the sidescreen is activated, a navigation bar is shown on the left-hand side of the user
interface.
This navigation bar can be used to switch directly to the desired operating area, and to show
and hide the sidescreen.
Multitouch operation with SINUMERIK Operate
3.5 Expansion with side screen
Turning
Operating Manual, 06/2019, A5E44903486B AB 79
