Parameter Description Unit
Z1
Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1. - (for tip centering only)
mm
DT
● Dwell time (at final drilling depth) in seconds
● Dwell time (at final drilling depth) in revolutions
s
rev
10.1.3 Drilling (CYCLE82)
Function
With the "Drilling" function, the tool drills with the programmed spindle speed and feedrate
down to the specified final drilling depth (shank or tip).
The tool is retracted after a programmed dwell time has elapsed.
Clamping the spindle
For ShopTurn, the "Clamp spindle" function can be set up by the machine manufacturer.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Input simple
For simple machining operations, you have the option to reduce the wide variety of parameters
to the most important parameters using the "Input" selection field. In this "Input simple" mode,
the hidden parameters are allocated a fixed value that cannot be adjusted.
Machine manufacturer
Various defined values can be pre-assigned using setting data.
Please refer to the machine manufacturer's specifications.
If the workpiece programming requires it, you can display and change all of the parameters
using "Input complete".
See also
Clamping the spindle (Page 296)
Programming technology functions (cycles)
10.1 Drilling
Turning
348 Operating Manual, 06/2019, A5E44903486B AB
