Parameters Description Unit
Machining
● 1. Cut
The thread is drilled in one cut without interruption.
● Chipbreaking
The drill is retracted by the retraction distance V2 for chipbreaking.
● Stock removal
The drill is retracted from the workpiece for stock removal.
Z0 Reference point Z) mm
Z1 End point of the thread (abs) or thread length (inc) mm
D Maximum depth infeed - (for stock removal or chipbreaking only) mm
Retraction - (only for "chipbreaking" operation)
Retraction distance
● Manual
● Automatic
V2 Retraction distance (only for "manual" retraction)
Distance through which the tap is retracted for chipbreaking.
V2 = automatic: The tool is retracted by one revolution.
mm
10.7.3 Transformations
To make programming easier, you can transform the coordinate system. Use this possibility, for
example, to rotate the coordinate system.
Coordinate transformations only apply in the actual program.
You can define the following transformations:
● Offset
● Rotation
● Scaling
● Mirroring
● Rotation C axis
You can select between a new or an additive coordinate transformation.
In the case of a new coordinate transformation, all previously defined coordinate
transformations are deselected. An additive coordinate transformation acts in addition to the
currently selected coordinate transformations.
Programming technology functions (cycles)
10.7 Additional cycles and functions in ShopTurn
Turning
Operating Manual, 06/2019, A5E44903486B AB 631
